rim size 6.00x13, hole number 5, rim centre hole Ø 67mm, bolt circle 112mm, offset +30, colour silver RAL9006, R12 ball-head, load capacity 950kg at 140km/h.
BC: dimension A 930mm, OHF: dimension C 1380mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 27-33mm, swing arm position 25°, axle profile 80mm, ball-head wheel bolts M12x1.5.
consisting of brake shoes, pressure springs, tension springs, cover plates, casting number brake shoes 563267 and 563268, for one axle (2 wheel brakes left + right).
rim size 6.75x17.5, hole number 6, rim centre hole Ø 161mm, bolt circle 205mm, offset 0, A2, radial, LKW tyre 215/75 R 17.5, load index 135/133J, 18 PR, load capacity 2180kg at 100km/h.
connection 166mm, nose load 120kg, drawbar installation version top, can be combined with AL-KO wheel brake 1637 / 2051, with coupling head AK 270, Soft-Dock.
rim size 4.50x13, hole number 5, rim centre hole Ø 66.5mm, bolt circle 112mm, offset +30, colour silver RAL9006, R12 ball-head, load capacity 710kg at 140km/h.
rim size 4.00x13, hole number 4, rim centre hole Ø 85mm, bolt circle 130mm, offset +20, colour silver RAL9006, R14 ball-head, load capacity 670kg at 140km/h.
build design radial, tyre size 195/70 R 14, TL (tubeless), load index 96, speed index N, tread AW-414, specification M+S, load capacity 710kg at 140km/h, inflation pressure 2.7 bar.
build design radial, tyre size 185/65 R 14, TL (tubeless), load index 93, speed index N, tread AW-414, specification M+S, load capacity 650kg at 140km/h, inflation pressure 2.7 bar.
build design radial, tyre size 155/80 R 13, TL (tubeless), load index 84, speed index N, tread AW-414, specification M+S, load capacity 500kg at 140km/h, inflation pressure 2.7 bar.
build design radial, tyre size 195/55 R 10 C, TL (tubeless), load index 98/96, speed index P, tread CR-966, specification M+S, load capacity 750kg at 150km/h, inflation pressure 6.25 bar.
BC: dimension A 900mm, OHF: dimension C 1430mm, wheel connection 205x6, wheel brake type 3081 A, offset (ET) 0mm, swing arm position 20°, axle profile 120mm, wheel nuts M18x1.5 ball.
