AL-KO Braked axle 900 - 2000kg DELTA, axle type SI-N - These axles must only be installed in caravans!

AL-KO SEMI-TRAILING ARM AXLES HAVE BEEN DEVELOPED AND APPROVED SPECIFICALLY FOR USE IN CARAVANS.
CARAVANS ARE ONLY OPERATED WITHIN THE NOMINAL LOAD RANGE, AND ARE VERY
DEMANDING IN TERMS OF DRIVING DYNAMICS DUE TO
THEIR DESIGN, PARTICULARLY AT HIGH SPEEDS.
THESE AXLES HAVE BEEN DEVELOPED AND APPROVED PRECISELY FOR THESE BOUNDARY CONDITIONS.
NO OTHER APPLICATION AREA IS PERMITTED.

Braked axle 650kg axle type B 700-3 - ERIBA ERIBELLE
BC: dimension A 940mm, OHF: dimension C 1520mm, wheel connection 100x4, wheel brake type 1637, offset (ET) 27-33mm, swing arm position 0°, axle profile 71mm.
Price 1.325,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1800kg EURO Plus axle type DELTA SI 18-1
BC: dimension A 1760mm, OHF: dimension C 2280mm, wheel connection 112x5, wheel brake type 2361, offset (ET) 30mm, swing arm position 15°, axle profile 110mm, ball-head wheel bolts M12x1.5.
Price 2.050,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type DELTA SIN 12 FENDT
BC: dimension A 1495mm, OHF: dimension C 1980mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.450,00 EUR Incl. tax Excl. Shipping costs
Braked axle 900kg EURO1 axle type B 850-5 - GOBUR CARAVANS
BC: dimension A 1035mm, OHF: dimension C 1479mm, wheel connection 100x4, wheel brake type 1637, offset (ET) 27-33mm, swing arm position 25°, axle profile 80mm.
Price 1.460,00 EUR Incl. tax Excl. Shipping costs
Braked axle 2000kg EURO1 axle type DELTA SI-18-3
BC: dimension A 1681mm, OHF: dimension C 2198mm, wheel connection 112x5, wheel brake type 2361, offset (ET) 30mm, swing arm position 15°, axle profile 110mm, ball-head wheel bolts M12x1.5.
Price 1.940,00 EUR Incl. tax Excl. Shipping costs
Braked axle 900kg EURO1 axle type B 850-5 - DETHLEFFS RM2
BC: dimension A 1370mm, OHF: dimension C 1818mm, wheel connection 100x4, wheel brake type 1637, offset (ET) 27-33mm, swing arm position 25°, axle profile 80mm.
Price 1.350,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1360kg EURO Plus axle type DELTA SIN 12-3 - BĂĽrstner
BC: dimension A 1550mm, OHF: dimension C 2030mm, wheel connection 112x5, wheel brake type 2051 vers. Ab, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.495,00 EUR Incl. tax Excl. Shipping costs
