BPW

RUNNING WELL FOR YOU. BPW BERGISCHE AXLES

AL-KO Technology Paderborn GmbH specialises in the development and manufacture of complete running gear technology for car trailers and self-propelled vehicles. The location has developed from a labour-intensive wagon maker into an innovative, modern industrial company. Since 2017 the former BPW Fahrzeugtechnik has been part of the global technology company DexKo Global Inc., a worldwide market leader for trailer axles and chassis components in the lightweight segment. Read more...

Underpinning Your Progress.
The range of running gear for towable machinery, car and light truck trailers, caravans and cab & engine vehicles.



Braked axle 1050kg SWING axle type CB 1055, 46.21.379.455 HUMBAUR
BC: dimension AM 1550mm, OHF: dimension FL 2000mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 1.129,90 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1350kg axle type CB 1355, 46.25.379.699, HUMBAUR
BC: dimension AM 1100mm, OHF: dimension FL 1550mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm.
Price 650,00 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 3.5-3, 2500 to 3500kg, 48.51.581.005
connection 166mm, nose load 150kg, drawbar installation version top, combined with BPW wheel brake S2005-7, S2504-7 and S3006-7 RASK, with coupling head EM 350 R-D.
Price 795,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1050kg axle type SCB 1054, 46.21.379.906, 4012954
BC: dimension AM 1606mm, OHF: dimension FL 2270mm, wheel connection 100x4, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 1.169,90 EUR Incl. tax Excl. Shipping costs
Braked tandem axle unit 2700kg SWING axle type CB 2/1355, 49.25.379.154
BC: dimension AM 1700mm, OHF: dimension FL 2150mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 1.555,00 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 3.5-3, 2500 to 3500kg, 48.51.581.006
connection 166mm, nose load 150kg, drawbar installation version top, combined with BPW wheel brake S2005-7, S2504-7 and S3006-7 RASK, with coupling head EM 350 R-D.
Price 765,00 EUR Incl. tax Excl. Shipping costs
Braked axle 2500kg RONDO axle type DS 2506, 45.41.373.059
BC: dimension AM 1600mm, OHF: dimension SP 2100mm, wheel connection 205x6, wheel brake type S 3006-7 RASK, offset (ET) 0mm, swing arm position 0°, axle profile 92mm, M18x1.5.
Price 4.790,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1350kg axle type CB 1355, 2250423, WM MEYER
BC: dimension AM 735mm, OHF: dimension FL 1200mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5, ALKO 46.25.379.484, BPW 4013242, WM-Meyer 2250423.
Price 1.050,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1000kg axle type CB 1004, 46.20.382.005, 4012744
BC: dimension AM 1450mm, OHF: dimension FL 1960mm, wheel connection 100x4, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 856,50 EUR Incl. tax Excl. Shipping costs
Braked tandem axle unit 2700kg SWING axle type CB 2/1355, 4014505
BC: dimension AM 1200mm, OHF: dimension FL 1640mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 3.190,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1800kg axle type CB 1805, 4021144
BC: dimension AM 1000mm, OHF: dimension FL 1490mm, wheel connection 112x5, wheel brake type S 2504-7 RASK, offset (ET) 35mm, swing arm position 20°, axle profile 80/82mm, ball-head wheel bolts M12x1.5.
Price 884,20 EUR Incl. tax Excl. Shipping costs
Braked axle 1050kg SWING axle type CB 1055, 46.21.379.633
BC: dimension AM 1650mm, OHF: dimension FL 2100mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 590,80 EUR Incl. tax Excl. Shipping costs
Braked axle 1500kg axle type SCB 1505, 46.27.379.911, 46.27.379.935
BC: dimension AM 1505mm, OHF: dimension FL 1995mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 95mm, ball-head wheel bolts M12x1.5.
Price 1.230,00 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 2.0-3, 1250 to 2000kg, 48.36.581.096
connection 166mm, nose load 150kg, drawbar installation version top + bottom, combined with BPW wheel brake S1704-7, S2005-7 and S2504-7 RASK, with coupling head WW 220 R-B.
Price 495,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1700kg axle type SCB 1605, 46.29.368.907, 4024036
BC: dimension AM 1605mm, OHF: dimension FL 2170mm, wheel connection 112x5, wheel brake type S 2504-7 RASK, offset (ET) 30mm, swing arm position 25°, axle profile 95mm, ball-head wheel bolts M12x1.5.
Price 1.699,00 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.030
BC: dimension AM 1000mm, OHF: dimension FL 1430mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 482,10 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 1.0-3, 540 to 1000kg, 48.20.581.025
connection 166mm, nose load 75kg, drawbar installation version top, combined with BPW wheel brake S1704-7 and S2005-7 RASK, with coupling head WW 13-N.
Price 324,90 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1300kg axle type WM 1300, 2250425, WM MEYER
BC: dimension AM 1000mm, OHF: dimension FL 1425mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 0°.
Price 1.050,00 EUR Incl. tax Excl. Shipping costs
Axle shock absorber A2-110-20/160 incl. fixing bolts
for BPW/AL-KO axles trailing arm and semi-trailing arm, single axle up to 1350kg, tandem axle up to 2700kg, colour blue.
Price 155,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1350kg RONDO axle type DB 1355 ECO-1, 45.25.362.042 Hobby Elegance 470 UB
BC: dimension AM 1550mm, OHF: dimension FL 2010mm, wheel connection 112x5, wheel brake type S 2005-5 RASK, offset (ET) 30mm, swing arm position 15°, axle profile 70mm, ball-head wheel bolts M12x1.5.
Price 1.850,00 EUR Incl. tax Excl. Shipping costs
Braked half axles 2500kg axle type CSST 2506, left, 46.41.373.027
BC: dimension A 410mm, OHF: dimension C 650mm, wheel connection 205x6, wheel brake type S 3006-7 RASK, offset (ET) 0mm, swing arm position 0°, axle profile 110mm, wheel nuts M18x1.5 ball.
Price 1.152,90 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 1.2-1.1 B height-adjustable with drawbar section up to 1200kg, 47.23.403.014
drawbar length L 1070mm, drawbar section K 82.5mm, with DIN drawbar eye dimension A 655mm, height B 0-375mm, intermediate piece V 500mm, perm. nose load 100kg.
Price 959,50 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1350kg axle type CB 1354, 46.25.379.185
BC: dimension AM 1450mm, OHF: dimension FL 1960mm, wheel connection 100x4, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 25°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 999,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1500kg axle type CB 1505, 46.27.379.639, 4013563
BC: dimension AM 1636mm, OHF: dimension FL 2200mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 25°, axle profile 82mm, ball-head wheel bolts M12x1.5.
Price 1.590,00 EUR Incl. tax Excl. Shipping costs
