RUNNING WELL FOR YOU. BPW BERGISCHE AXLES

AL-KO Technology Paderborn GmbH specialises in the development and manufacture of complete running gear technology for car trailers and self-propelled vehicles. The location has developed from a labour-intensive wagon maker into an innovative, modern industrial company. Since 2017 the former BPW Fahrzeugtechnik has been part of the global technology company DexKo Global Inc., a worldwide market leader for trailer axles and chassis components in the lightweight segment. Read more...

Underpinning Your Progress.
The range of running gear for towable machinery, car and light truck trailers, caravans and cab & engine vehicles.



kit 2x Axle shock absorber black
BPW (AL-KO) kit 2x Axle shock absorber black
for BPW axles RONDO, weight range 1050-1800kg axle load, L min = 237mm, L max. =337mm, installation dimension about 245mm, colour black, with articulation connection eyes and fixing bolts.
Price 299,90 EUR Incl. tax Excl. Shipping costs
Clamping shell, single axle, vers. 2
BPW (AL-KO) Clamping shell, single axle, vers. 2
drawbar tube ⌀70mm, axle profile square 60mm, for unbraked trailers.
Price 168,50 EUR Incl. tax Excl. Shipping costs
Braked tandem axle unit 2100kg SWING axle type CB 2/1055, 49.21.379.188
BPW (AL-KO) Braked tandem axle unit 2100kg SWING axle type CB 2/1055, 49.21.379.188
BC: dimension AM 1900mm, OHF: dimension FL 2350mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 1.540,00 EUR Incl. tax Excl. Shipping costs
Braked tandem axle unit 2100kg SWING axle type CB 2/1055, 49.21.379.179
BPW (AL-KO) Braked tandem axle unit 2100kg SWING axle type CB 2/1055, 49.21.379.179
BC: dimension AM 1450mm, OHF: dimension FL 1900mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 1.495,00 EUR Incl. tax Excl. Shipping costs
Braked tandem axle unit 2100kg SWING axle type CB 2/1055, 49.21.379.163
BPW (AL-KO) Braked tandem axle unit 2100kg SWING axle type CB 2/1055, 49.21.379.163
BC: dimension AM 1650mm, OHF: dimension FL 2100mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 1.515,00 EUR Incl. tax Excl. Shipping costs
Braked tandem axle unit 2100kg SWING axle type CB 2/1054, 49.21.379.135
BPW (AL-KO) Braked tandem axle unit 2100kg SWING axle type CB 2/1054, 49.21.379.135
BC: dimension AM 1250mm, OHF: dimension FL 1700mm, wheel connection 100x4, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 1.475,00 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1350kg RONDO axle type DB 1355, 45.25.379.669
BPW (AL-KO) Braked tandem front axle 1350kg RONDO axle type DB 1355, 45.25.379.669
BC: dimension AM 1450mm, OHF: dimension FL 1900mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 70mm, taper-head wheel bolts M12x1.5.
Price 1.087,90 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1350kg RONDO axle type DB 1355, 45.25.379.657
BPW (AL-KO) Braked tandem front axle 1350kg RONDO axle type DB 1355, 45.25.379.657
BC: dimension AM 1850mm, OHF: dimension FL 2300mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 70mm, ball-head wheel bolts M12x1.5.
Price 1.116,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1350kg RONDO axle type DB 1355, 45.25.379.603
BPW (AL-KO) Braked axle 1350kg RONDO axle type DB 1355, 45.25.379.603
BC: dimension AM 1150mm, OHF: dimension FL 1600mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 70mm, taper-head wheel bolts M12x1.5.
Price 1.065,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1350kg RONDO axle type DB 1355, 45.25.379.583
BPW (AL-KO) Braked axle 1350kg RONDO axle type DB 1355, 45.25.379.583
BC: dimension AM 1150mm, OHF: dimension FL 1600mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 70mm, ball-head wheel bolts M12x1.5.
Price 1.064,90 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1350kg axle type CB 1355, 46.24.379.209, WÖRMANN
BPW (AL-KO) Braked axle SWING 1350kg axle type CB 1355, 46.24.379.209, WÖRMANN
BC: dimension AM 1200mm, OHF: dimension FL 1625mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 0°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 920,00 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1054, 46.21.379.671
BPW (AL-KO) Braked tandem front axle 1050kg SWING axle type CB 1054, 46.21.379.671
BC: dimension AM 1550mm, OHF: dimension FL 2000mm, wheel connection 100x4, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 585,30 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1054, 46.21.379.669
BPW (AL-KO) Braked tandem front axle 1050kg SWING axle type CB 1054, 46.21.379.669
BC: dimension AM 1450mm, OHF: dimension FL 1900mm, wheel connection 100x4, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 579,80 EUR Incl. tax Excl. Shipping costs
Braked axle 1050kg SWING axle type CB 1055, 46.21.379.630
BPW (AL-KO) Braked axle 1050kg SWING axle type CB 1055, 46.21.379.630
BC: dimension AM 1500mm, OHF: dimension FL 1950mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 519,90 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAV 2.7-4 with overrun device AE 2.7-1 A height-adjustable, with drawbar section 1860 to 2700kg, 47.43.470.053
BPW (AL-KO) Drawbar installation ZAV 2.7-4 with overrun device AE 2.7-1 A height-adjustable, with drawbar section 1860 to 2700kg, 47.43.470.053
drawbar length L 2280mm, measure B 0-520mm, FD at max. 2700kg: 3500mm, drawbar section K square 150x132mm, spacer V 600mm, perm. nose load 150kg, without hitch components, for wheel brake S 2005-7, S 2504-7 and S 3006-5.
Price 2.775,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZKV 20.1 A with overrun device AK 2008 height-adjustable, with drawbar section 1300 to 2000kg, 47.36.471.033
BPW (AL-KO) Drawbar installation ZKV 20.1 A with overrun device AK 2008 height-adjustable, with drawbar section 1300 to 2000kg, 47.36.471.033
drawbar length L 2800mm, FD at max. 2000kg: 1853mm, drawbar section K round 101.6x10mm, spacer V 415mm, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 2.648,60 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZKV 13.1 A with overrun device AK 1308 height-adjustable, with drawbar section cranked 650 to 1300kg, 47.24.471.083
BPW (AL-KO) Drawbar installation ZKV 13.1 A with overrun device AK 1308 height-adjustable, with drawbar section cranked 650 to 1300kg, 47.24.471.083
drawbar length L 2100mm, FD at max. 1300kg: 1664mm, drawbar section K round 88.9x8.8mm, spacer V 415mm, perm. nose load 100kg, with coupling head EM 150 R-B, for wheel brake S 1704-7 and S 2005-7.
Price 2.547,50 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAR 2.0-1 A with overrun device PAV/SR 2.0 X drawbar section straight 1089 to 2000kg, 48.36.181.041
BPW (AL-KO) Drawbar installation ZAR 2.0-1 A with overrun device PAV/SR 2.0 X drawbar section straight 1089 to 2000kg, 48.36.181.041
drawbar length L 2300mm, FD at max. 2000kg: 1385mm, drawbar section K round 88.9x6.3mm, measure HA 58mm, thread G M10, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 677,90 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 2.0-1 with overrun device ZAAQ2.0 / ZDG8-3 drawbar section straight 1250 to 2000kg, 48.36.181.074
BPW (AL-KO) Drawbar installation ZAAR 2.0-1 with overrun device ZAAQ2.0 / ZDG8-3 drawbar section straight 1250 to 2000kg, 48.36.181.074
drawbar length L 2300mm, FD at max. 2000kg: 1360mm, drawbar section K square 80x5.0mm, measure HA 55mm, thread G M10, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 761,60 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 1.6-1 with overrun device ZAAQ1.6 / ZDG7-3 drawbar section straight 800 to 1600kg, 48.29.181.058
BPW (AL-KO) Drawbar installation ZAAR 1.6-1 with overrun device ZAAQ1.6 / ZDG7-3 drawbar section straight 800 to 1600kg, 48.29.181.058
drawbar length L 3500mm, FD at max. 1600kg: 1200mm, drawbar section K square 70x5.0mm, measure HA 50mm, thread G M10, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 730,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 1.35-1 with overrun device ZAAQ1.35-3 / ZDG7-3 drawbar section straight 750 to 1350kg, 48.25.181.099
BPW (AL-KO) Drawbar installation ZAAR 1.35-1 with overrun device ZAAQ1.35-3 / ZDG7-3 drawbar section straight 750 to 1350kg, 48.25.181.099
drawbar length L 2500mm, FD at max. 1350kg: 1210mm, drawbar section K square 70x4.0mm, measure HA 50mm, thread G M10, perm. nose load 100kg, with coupling head EM 150 R-B, for wheel brake S 1704-7 and S 2005-7.
Price 630,10 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 2.0-3, 1250 to 2000kg, 48.36.581.094, 4014343, WM MEYER
BPW (AL-KO) Overrun device V type ZAF 2.0-3, 1250 to 2000kg, 48.36.581.094, 4014343, WM MEYER
connection 166mm, nose load 150kg, drawbar installation version top + bottom, combined with AL-KO wheel brake 2051 and 2361, with coupling head EM 220 R-A.
Price 399,00 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 3.0-3, 1800 to 3000kg, 48.46.581.010
BPW (AL-KO) Overrun device V type ZAF 3.0-3, 1800 to 3000kg, 48.46.581.010
connection 166mm, nose load 150kg, drawbar installation version top + bottom, combined with BPW wheel brake S2005-7, S2504-7 and S3006-7 RASK, with coupling head EM 300 R-B.
Price 625,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1500kg axle type CB 1505, 46.27.379.781
BPW (AL-KO) Braked axle SWING 1500kg axle type CB 1505, 46.27.379.781
BC: dimension AM 1825mm, OHF: dimension FL 2285mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm.
Price 690,00 EUR Incl. tax Excl. Shipping costs
