for AL-KO axles trailing arm and semi-trailing arm, single axle up to 2000kg, tandem axle up to 3500kg, colour red, with articulation connection eyes and fixing bolts.
sheath length (H) 2000mm, cable length (S) 2210mm, can be used with wheel brake 1636G, 1637, 2051 and 2361 from year of manufacture 01/1989, bell internal diam. 23.3mm, outside 26mm.
wheel load per hub up to max. 140 km/h 375kg, up to max. 40 km/h 450kg, wheel connection (G) 100x4, thread M12x1.5, offset 27-45, dimension A 203.5mm, dimension B 83.5mm, dimension C 39.5mm, bearing type Compact.
sheath length (H) 890mm, cable length (S) 1100mm, can be used with wheel brake 1636G, 1637, 2051 and 2361 from year of manufacture 01/1989, bell internal diam. 23.3mm, outside 26mm.
total length K (at -5°) 3085mm, drawbar length E 1650mm, drawbar section 120x160x6mm, intermediate piece 700mm, perm. nose load 350kg, without hitch components, for wheel brake 2051.
total length K (at -5°) 2552mm, drawbar length E 1250mm, drawbar section 100x160x5mm, intermediate piece 700mm, perm. nose load 120kg, without hitch components, for wheel brake 1637 / 2051.
connection 166mm, nose load 100kg, drawbar installation version top, can be combined with AL-KO wheel brake 1637 / 2051, with coupling head AK 161, Soft-Dock.
connection 186mm, nose load 150kg, drawbar installation version top + bottom, can be combined with AL-KO wheel brake 3062 / 3081, with coupling head AK 351.
connection 130mm, nose load 75kg, drawbar installation version top, can be combined with AL-KO wheel brake 1636G / 1637, with coupling head AK 161, Soft-Dock.
