AL-KO

Home / Brands / AL-KO

JUST ORIGINAL PARTS

LIFE-TIME SUPPORT

SALE

POSITIVE REVIEWS

FTF Braked axle 650kg axle type B 700-3 - ERIBA-HYMER Eribelle FAS
AL-KO FTF Braked axle 650kg axle type B 700-3 - ERIBA-HYMER Eribelle FAS
BC: dimension A 940mm, OHF: dimension C 1520mm, wheel connection 100x4, wheel brake type 1636G, offset (ET) 27-33mm, swing arm position 0°, axle profile 71mm, taper-head wheel bolts M12x1.5.
Price 1.325,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO COMPACT axle type B 1200-5, watertight, Mecanorem
AL-KO Braked axle 1300kg EURO COMPACT axle type B 1200-5, watertight, Mecanorem
BC: dimension A 1320mm, OHF: dimension C 1880mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm.
Price 859,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO COMPACT axle type B 1200-5 - RSA - SATELLITE MX111
AL-KO Braked axle 1300kg EURO COMPACT axle type B 1200-5 - RSA - SATELLITE MX111
BC: dimension A 1466mm, OHF: dimension C 1942mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 795,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1360kg EURO Compact axle type DELTA SIN 12-3
AL-KO Braked axle 1360kg EURO Compact axle type DELTA SIN 12-3
BC: dimension A 1495mm, OHF: dimension C 2070mm, wheel connection 112x5, wheel brake type 2051 vers. AB, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.410,00 EUR Incl. tax Excl. Shipping costs
COMPACT corner steady load capacity 500kg
AL-KO COMPACT corner steady load capacity 500kg
length 438mm, height max. 410mm stationary nose load max. 500kg, perm. gross weight of the trailer (recommendation) max. 1000kg, galvanised, push-on crank.
Price 74,90 EUR Incl. tax Excl. Shipping costs
Loose crank, 693555
AL-KO Loose crank, 693555
length 105mm.
Price 17,90 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø48mm round Compact, 1222556
AL-KO Jockey wheel ø48mm round Compact, 1222556
stationary nose load max. 150kg, nose load when manoeuvring max.90kg, rim steel, wheel 225x70mm solid rubber, extended length 220mm.
Price 61,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO COMPACT axle type B 1200-5, watertight, Mécanorem
AL-KO Braked axle 1300kg EURO COMPACT axle type B 1200-5, watertight, Mécanorem
BC: dimension A 1270mm, OHF: dimension C 1860mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 30-33mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 895,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation 75 VR with coupling head AK 7, bottom installation with safety wire
AL-KO Drawbar installation 75 VR with coupling head AK 7, bottom installation with safety wire
drawbar ⌀50mm square with mounting plate V, holes (screw connection) vertical 13mm, hole distance 166mm, perm. gross weight 750kg, nose load 75kg, material: steel.
Price 105,00 EUR Incl. tax Excl. Shipping costs
Mudguard, twin-axle trailer, plastic, left, HUMBAUR
AL-KO Mudguard, twin-axle trailer, plastic, left, HUMBAUR
width (B) 300mm, height (H) 281mm, span width (S) 286mm, RAL colour similar to black RAL 9017.
Price 25,90 EUR Incl. tax Excl. Shipping costs
2LINK, single axle trailer
AL-KO 2LINK, single axle trailer
Tire Pressure Monitoring System (TPMS).
Price 330,00 EUR Incl. tax Excl. Shipping costs
Storage box for car trailer, cover hinges on the side
AL-KO Storage box for car trailer, cover hinges on the side
max. load 20kg suspended, external dimensions LxWxH 515x226x272mm, height inc. turning handle 305mm, internal dimensions LxWxH 445x145x220mm.
Price 171,00 EUR Incl. tax Excl. Shipping costs
Towball Typ 167
AL-KO Towball Typ 167
hole pattern 83x56mm, 4 holes Ø11mm, nose load 200kg, D/Dc value 17.5 kN, surface treatment black primed.
Price 202,00 EUR Incl. tax Excl. Shipping costs
Tandem adapter bracket, bolt on
AL-KO Tandem adapter bracket, bolt on
hot-dip galvanised, up to 3500kg, hole spacing 50mm, install adapter bracket behind the axle in the driving direction (old adapter bracket in front of the axle).
Price 19,90 EUR Incl. tax Excl. Shipping costs
Bowden cable 1231868 for overrun device with thread and eyelet
AL-KO Bowden cable 1231868 for overrun device with thread and eyelet
sheath length (A) 707mm, cable length (B) 937mm, cable thickness (C) 6mm, thread (D) M12, suitable for types 350 VB Basic.
Price 79,90 EUR Incl. tax Excl. Shipping costs
Shock absorber for straight axle
AL-KO Shock absorber for straight axle
750 / 1500 / 1800kg and tandem 3000 / 3500kg
Price 49,90 EUR Incl. tax Excl. Shipping costs
Overrun device V type 251S, 1500 to 2700kg, slack point handbrake lever, without clamp
AL-KO Overrun device V type 251S, 1500 to 2700kg, slack point handbrake lever, without clamp
connection 166mm, installation top + bottom, can be combined with AL-KO wheel brake 2361, with coupling head AK 270, Soft-Dock.
Price 410,00 EUR Incl. tax Excl. Shipping costs
Overrun device square type 90S/3, 700 to 1000kg
AL-KO Overrun device square type 90S/3, 700 to 1000kg
connection dimension B 60mm, nose load 75kg, can be combined with AL-KO wheel brake 1637 / 2051, with coupling head AK 161, Soft-Dock.
Price 420,00 EUR Incl. tax Excl. Shipping costs
Braked tandem axle unit 2000kg BASIC axle type 2xB 850
AL-KO Braked tandem axle unit 2000kg BASIC axle type 2xB 850
BC: dimension A 1550mm, OHF: dimension C 2000mm, wheel connection 112x5, wheel brake type 1637, offset (ET) 27-33mm, swing arm position 25°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 1.494,00 EUR Incl. tax Excl. Shipping costs
Braked tandem axle unit 2000kg BASIC axle type 2xB 850
AL-KO Braked tandem axle unit 2000kg BASIC axle type 2xB 850
BC: dimension A 1550mm, OHF: dimension C 2000mm, wheel connection 100x4, wheel brake type 1637, offset (ET) 27-33mm, swing arm position 25°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 1.494,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1500kg BASIC axle type B 1600-3
AL-KO Braked axle 1500kg BASIC axle type B 1600-3
BC: dimension A 1625mm, OHF: dimension C 2075mm, wheel connection 112x5, wheel brake type 2051 Ab, offset (ET) 30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 795,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1500kg BASIC axle type B 1600-3
AL-KO Braked axle 1500kg BASIC axle type B 1600-3
BC: dimension A 1200mm, OHF: dimension C 1650mm, wheel connection 112x5, wheel brake type 2051 Ab, offset (ET) 30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 737,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1350kg PLUS axle type B 1200-5
AL-KO Braked axle 1350kg PLUS axle type B 1200-5
BC: dimension A 1100mm, OHF: dimension C 1550mm, wheel connection 112x5, wheel brake type 2051, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 709,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1350kg PLUS axle type B 1200-5
AL-KO Braked axle 1350kg PLUS axle type B 1200-5
BC: dimension A 850mm, OHF: dimension C 1300mm, wheel connection 112x5, wheel brake type 2051, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 703,00 EUR Incl. tax Excl. Shipping costs
Page 17 of 470
