screw stroke (extended length) 400mm, maxi. static load 3800kg, working pressure 100 bar, max. working pressure 200 bar, dimension B 635mm, dimension D 750mm, dimension G 250mm.
screw stroke (extended length) 400mm, maxi. static load 1950kg, working pressure 100 bar, max. working pressure 200 bar, dimension B 630mm, dimension D 720mm, dimension G 220mm.
screw stroke (extended length) 700mm, maxi. static load 2800kg, working pressure 100 bar, max. working pressure 200 bar, dimension B 930mm, dimension D 1010mm, dimension G 280mm.
screw stroke (extended length) 420mm, maxi. static load 10000kg, dimension B 700mm, dimension C 420mm, dimension D 820mm, dimension E 250mm, dimension G 250mm, dimension H 300mm, dimension I 275mm.
screw stroke (extended length) 300mm, maxi. static load 4535kg, dimension B 500mm, dimension C 380mm, dimension D 685mm, dimension E 225mm, dimension G 220mm, dimension H 276mm.
screw stroke (extended length) 170mm, maxi. static load 6000kg, dimension B 325mm, dimension C 225mm, dimension D 565mm, dimension E 220mm, dimension G 220mm, dimension I 515mm.
dimension A 176mm, dimension B 119mm, dimension C 67mm, dimension D 5mm, dimension E 13mm, dimension F 144mm, dimension G 70mm, dimension H 67mm, dimension I 19°.
screw stroke (extended length) 470mm, maxi. static load 10000kg, dimension B 900mm, dimension D 960mm, dimension E 250mm, dimension G 245mm, dimension I 105mm.
screw stroke (extended length) 700mm, maxi. static load 3800kg, working pressure 100 bar, max. working pressure 200 bar, dimension B 935mm, dimension D 1050mm, dimension G 250mm.
