Home / CHASSIS PARTS / CHASSIS PARTS AL-KO / OVERRUN DEVICES / OVERRUN DEVICES V / TOWBAR CONNECTIONS V, TOWBAR CONNECTION, JOCKEY WHEEL CROSSMEMBER, BRAKE ROD / TOWBAR CONNECTIONS V 1000KG TO 3500KG / Steday leg ⌀51mm, side crank and reductions gears, double speed, type LT 2103W, galvanised, for agricultural machines and trailers, machines for building industry, implements for road maintenance and snow
screw stroke (extended length) 245mm, maxi. static load 900kg, dimension D 420mm, dimension E 167mm, dimension G 120x140mm, dimension I 260mm. Read more...
| Outer tube |
⌀51mm |
| Screw stroke (extended length) | 245mm |
| Maxi. static load | 900kg |
| Dimension D |
420mm |
| Dimension E |
167mm |
| Dimension G |
120x140mm |
| Dimension I |
260mm |
Here, you can find the catalogue page(s) as a convenient PDF download.
