RUNNING WELL FOR YOU. BPW BERGISCHE AXLES

AL-KO Technology Paderborn GmbH specialises in the development and manufacture of complete running gear technology for car trailers and self-propelled vehicles. The location has developed from a labour-intensive wagon maker into an innovative, modern industrial company. Since 2017 the former BPW Fahrzeugtechnik has been part of the global technology company DexKo Global Inc., a worldwide market leader for trailer axles and chassis components in the lightweight segment. Read more...

Underpinning Your Progress.
The range of running gear for towable machinery, car and light truck trailers, caravans and cab & engine vehicles.



Lowering axles down to 200mm, axle type RONDO DB 2/1805, tandem 3500kg, 49.32.368.507
BPW (AL-KO) Lowering axles down to 200mm, axle type RONDO DB 2/1805, tandem 3500kg, 49.32.368.507
BC: dimension AM 1900mm, OHF: dimension FL 2440mm, wheel connection 112x5, wheel brake type S 2504-7 RASK, offset (ET) 35mm, ball-head wheel bolts M12x1.5.
Price 4.274,40 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1800kg RONDO axle type DB 1805, 45.32.368.627
BPW (AL-KO) Braked tandem front axle 1800kg RONDO axle type DB 1805, 45.32.368.627
BC: dimension AM 1350mm, OHF: dimension FL 1850mm, wheel connection 112x5, wheel brake type S 2504-7 RASK, offset (ET) 35mm, swing arm position 13°, axle profile 92mm, ball-head wheel bolts M12x1.5.
Price 1.992,70 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1350kg RONDO axle type DB 1355, 45.25.379.670
BPW (AL-KO) Braked tandem front axle 1350kg RONDO axle type DB 1355, 45.25.379.670
BC: dimension AM 1500mm, OHF: dimension FL 1950mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 70mm, taper-head wheel bolts M12x1.5.
Price 1.260,50 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1350kg RONDO axle type DB 1355, 45.25.379.654
BPW (AL-KO) Braked tandem front axle 1350kg RONDO axle type DB 1355, 45.25.379.654
BC: dimension AM 1700mm, OHF: dimension FL 2150mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 70mm, ball-head wheel bolts M12x1.5.
Price 1.272,10 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg RONDO axle type DB 1055, 45.21.379.612
BPW (AL-KO) Braked tandem front axle 1050kg RONDO axle type DB 1055, 45.21.379.612
BC: dimension AM 1100mm, OHF: dimension FL 1550mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 70mm, taper-head wheel bolts M12x1.5.
Price 1.199,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1500kg axle type CB 1505, 46.27.379.502
BPW (AL-KO) Braked axle SWING 1500kg axle type CB 1505, 46.27.379.502
BC: dimension AM 1100mm, OHF: dimension FL 1550mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 835,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1050kg SWING axle type CB 1054, 46.21.379.618
BPW (AL-KO) Braked axle 1050kg SWING axle type CB 1054, 46.21.379.618
BC: dimension AM 1900mm, OHF: dimension FL 2350mm, wheel connection 100x4, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 546,90 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAV 2.7-4 with overrun device AE 2.7-1 A height-adjustable, with drawbar section 1860 to 2700kg, 47.43.470.081
BPW (AL-KO) Drawbar installation ZAV 2.7-4 with overrun device AE 2.7-1 A height-adjustable, with drawbar section 1860 to 2700kg, 47.43.470.081
drawbar length L 1900mm, measure B 0-520mm, FD at max. 2700kg: 3500mm, drawbar section K square 150x132mm, spacer V 600mm, perm. nose load 150kg, without hitch components, for wheel brake S 2005-7, S 2504-7 and S 3006-5.
Price 3.056,80 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAV 1.6-5 with overrun device AE 2.7-1 D height-adjustable, with drawbar section 1200 to 1600kg, 47.29.470.068
BPW (AL-KO) Drawbar installation ZAV 1.6-5 with overrun device AE 2.7-1 D height-adjustable, with drawbar section 1200 to 1600kg, 47.29.470.068
drawbar length L 2800mm, measure B 0-693mm, FD at max. 1600kg: 3000mm, drawbar section K square 120mm, spacer V 800mm, perm. nose load 150kg, without hitch components, for wheel brake S 1704-7 and S 2005-7.
Price 2.200,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZKV 35.1 B with overrun device AK 3510 A height-adjustable, with drawbar section 2500 to 3500kg, 47.51.473.034
BPW (AL-KO) Drawbar installation ZKV 35.1 B with overrun device AK 3510 A height-adjustable, with drawbar section 2500 to 3500kg, 47.51.473.034
drawbar length L 1900mm, FD at max. 3500kg: 3050mm, drawbar section K square 120x10mm, spacer V 550mm, perm. nose load 150kg, with drawbar eye DIN 40.0-02, for wheel brake S 2005-7, S 2504-7 and S 3006-7.
Price 4.399,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZKV 20.1 A with overrun device AK 2008 height-adjustable, with drawbar section 1300 to 2000kg, 47.36.471.031
BPW (AL-KO) Drawbar installation ZKV 20.1 A with overrun device AK 2008 height-adjustable, with drawbar section 1300 to 2000kg, 47.36.471.031
drawbar length L 1900mm, FD at max. 2000kg: 1853mm, drawbar section K round 101.6x10mm, spacer V 415mm, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 2.537,70 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 2.0-3 with overrun device ZAAQ2.0-3 / ZDG8-3 drawbar section cranked 1250 to 2000kg, 48.36.381.090
BPW (AL-KO) Drawbar installation ZAAR 2.0-3 with overrun device ZAAQ2.0-3 / ZDG8-3 drawbar section cranked 1250 to 2000kg, 48.36.381.090
drawbar length L 3500mm, FD at max. 2000kg: 1360mm, drawbar section K square 80x5.0mm, measure HA 55mm, thread G M10, perm. nose load 150kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 1.095,60 EUR Incl. tax Excl. Shipping costs
Brake shoes, wheel brake R 234-76, brake size 230x40mm
BPW (AL-KO) Brake shoes, wheel brake R 234-76, brake size 230x40mm
consisting of brake shoes, tension springs, hold down spring, for one axle (2 wheel brakes left + right).
Price 118,80 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 1.6-3, 750 to 1500kg, 48.27.581.044
BPW (AL-KO) Overrun device V type ZAF 1.6-3, 750 to 1500kg, 48.27.581.044
connection 166mm, nose load 150kg, drawbar installation version top, combined with BPW wheel brake S1704-7, S2005-7 and S2504-7 RASK, with coupling head WS 3000-D.
Price 650,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1350kg axle type CB 1355, 46.24.379.440
BPW (AL-KO) Braked axle 1350kg axle type CB 1355, 46.24.379.440
BC: dimension AM 1750mm, OHF: dimension FL 2200mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 1.150,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1050kg SWING axle type CB 1055, 46.21.379.304
BPW (AL-KO) Braked axle 1050kg SWING axle type CB 1055, 46.21.379.304
BC: dimension AM 1100mm, OHF: dimension FL 1580mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 650,00 EUR Incl. tax Excl. Shipping costs
Axle without brakes 2100kg FIAT DUCATO axle type DB 2100, 45.37.000.019
BPW (AL-KO) Axle without brakes 2100kg FIAT DUCATO axle type DB 2100, 45.37.000.019
BC: dimension AM 1220mm, OHF: dimension FL 1614mm, connection 82x82mm, WITHOUT wheel brake, swing arm position 5°, axle profile 92mm.
Price 5.600,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1500kg axle type CB 1505, 46.27.379.787
BPW (AL-KO) Braked axle SWING 1500kg axle type CB 1505, 46.27.379.787
BC: dimension AM 1550mm, OHF: dimension FL 2050mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 25°, axle profile 95mm.
Price 1.595,00 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 1.6-3, 800 to 1600kg, 48.29.581.075 Humbaur
BPW (AL-KO) Overrun device V type ZAF 1.6-3, 800 to 1600kg, 48.29.581.075 Humbaur
connection 166mm, nose load 100kg, drawbar installation version top, combined with BPW wheel brake S1704-7, S2005-7 and S2504-7 RASK, with coupling head WW220R-B.
Price 425,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1800kg axle type CB 1805, 46.32.368.269
BPW (AL-KO) Braked axle 1800kg axle type CB 1805, 46.32.368.269
BC: dimension AM 1450mm, OHF: dimension FL 1875mm, wheel connection 112x5, wheel brake type RB425, offset (ET) 27-40mm, swing arm position 20°, axle profile 95mm.
Price 895,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1500kg axle type CS 1505, 46.27.358.224
BPW (AL-KO) Braked axle 1500kg axle type CS 1505, 46.27.358.224
BC: dimension AM 1420mm, OHF: dimension FL 1870mm, wheel drawbar ⌀112x5, wheel brake type S 2005-7 RASK, offset (ET) 0mm, swing arm position 20°, axle profile 95mm.
Price 1.850,00 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 3.0-3, 1800 to 2800kg, 48.44.581.054
BPW (AL-KO) Overrun device V type ZAF 3.0-3, 1800 to 2800kg, 48.44.581.054
connection 167mm, nose load 150kg, drawbar installation version top + bottom, combined with BPW wheel brake S2005-7, S2504-7 and RB 2051, with coupling head WW 30-K.
Price 599,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1800kg axle type CB 1805, 46.32.368.217
BPW (AL-KO) Braked axle 1800kg axle type CB 1805, 46.32.368.217
BC: dimension AM 1250mm, OHF: dimension FL 1740mm, wheel connection 112x5, wheel brake type S 2504-7 RASK, offset (ET) 27-40mm, swing arm position 20°, axle profile 95mm, ball-head wheel bolts M12x1.5.
Price 1.355,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1500kg axle type CB 1505, 46.27.379.062, 46.27.379.072
BPW (AL-KO) Braked axle SWING 1500kg axle type CB 1505, 46.27.379.062, 46.27.379.072
BC: dimension AM 1200mm, OHF: dimension FL 1680mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 95mm, head wheel bolts M12x1.5.
Price 765,00 EUR Incl. tax Excl. Shipping costs
