BC: dimension A 900mm, OHF: dimension C 1430mm, wheel connection 205x6, wheel brake type 3081 A, offset (ET) 0mm, swing arm position 20°, axle profile 120mm, wheel nuts M18x1.5 ball.
EAB 1360mm, LG Corps 1424mm, width 1684mm, suitable for FIAT with chassis number ZFA23000005XXXXXX, without brakes. Scope of delivery corresponds to the technical drawing.
connection 166mm, nose load 150kg, drawbar installation version top + bottom, combined with BPW wheel brake S1704-7, S2005-7, S2504-7 and ALKO 2051, with coupling head WW 30-K.
rim size 6.00x16, hole number 5, rim centre hole Ø 66.5mm, bolt circle 112mm, offset +30, colour silver RAL9006, R12 ball-head, load capacity 900kg at 140km/h.
build design radial, tyre size 155 R 13 C, TL (tubeless), load index 91/89, speed index N, (90/88 R), tread TR603, specification M+S, load capacity 615/600kg at 140/170km/h, inflation pressure 4.5 bar.
build design radial, tyre size 155 R 12 C, TL (tubeless), load index 88/86, speed index N, tread UE-168, specification Verstärkt, load capacity 560kg at 140km/h, inflation pressure 4.33 bar.
build design radial, tyre size 165 R 13 C, TL (tubeless), load index 96, speed index N, tread KargoMax ST-6000, specification M+S, load capacity 710kg at 140km/h, inflation pressure 4.5 bar.
build design radial, tyre size 215 R 14 C, TL (tubeless), load index 116/114, speed index Q, tread TR 603, load capacity 1060kg at 140km/h, inflation pressure 4.75 bar.
BC: dimension A 1565mm, OHF: dimension C 2045mm, wheel connection 100x4, wheel brake type 2051, offset (ET) 27-33mm, swing arm position 25°, axle profile 97mm.
rim size 6.75x17.5, hole number 6, rim centre hole Ø 161mm, bolt circle 205mm, offset +128, colour silver RAL9006, A2, load capacity 2750kg at 100km/h.
consisting of brake shoes, pressure springs, tension springs, cover plates, spread hinge lock, (scope of delivery - see illustration), casting number brake shoes 384296 and 384481, for one axle (2 wheel brakes left + right).
rim size 5.50x15, hole number 5, rim centre hole Ø 66.5mm, bolt circle 112mm, offset +30, colour silver RAL9006, R12 ball-head, load capacity 900kg at 140km/h.
build design radial, tyre size 195/55 R 10 C, TL (tubeless), load index 98/96, speed index P, tread CR-966, specification M+S, load capacity 750kg at 150km/h, inflation pressure 6.25 bar.
connection 166mm, nose load 150kg, drawbar installation version top, combined with BPW wheel brake S2005-7 and S2504-7 RASK, with coupling head WW30-K.
rim size 5.50x14, hole number 5, rim centre hole Ø 67mm, bolt circle 112mm, offset +30, radial, tyre 185 R 14 C, load index 104N, load capacity 900kg at 140km/h.
