BC: dimension A 1020mm, OHF: dimension C 1470mm, wheel connection 100x4, wheel brake type 2051 A, offset (ET) 27-33mm, swing arm position 25°, axle profile 97mm.
BC: dimension A 1350mm, OHF: dimension C 1750mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 30-33mm, swing arm position 25°, axle profile 97mm, M14x1.5.
BC: dimension A 1518mm, OHF: dimension C 1900mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm.
tyre size summer, 235/65 R 16 C, TL (tubeless), load index 115/113, speed index T, tread NY-06, load capacity 1215/1150kg, inflation pressure 4,75 bar.
tyre size Trailer, 235/75 R 17.5, TL (tubeless), load index 143/141, speed index J, tread WTL 31, load capacity 2725/2575 kg, inflation pressure 8,30 bar.
tyre size front axle, 295/80 R 22.5, TL (tubeless), load index 154/149, speed index M, tread WSR 36, load capacity 3750/3250 kg, inflation pressure 9,0 bar.
tyre size front axle, 235/75 R 17.5, TL (tubeless), load index 143/141, speed index J, tread WGC 28, load capacity 2725/2575 kg, inflation pressure 9,0 bar.
BC: dimension A 1300mm, OHF: dimension C 1680mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 30-33mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
