total length A 3610mm, drawbar length C 2350mm, drawbar section 100x100x6mm, perm. nose load 100kg, with coupling head AK 270, for wheel brake 1637 / 2051.
consisting of brake shoes, pressure springs, tension springs, cover plates, casting number brake shoes 384509 or 1808747, for one axle (2 wheel brakes left + right).
consisting of brake shoes, pressure springs, tension springs, cover plates, spread hinge lock, (scope of delivery - see illustration), casting number brake shoes 384296 and 384481, for one axle (2 wheel brakes left + right).
total length K (at -5°) 3797mm, drawbar length E 2370mm, drawbar section 120x160x6mm, intermediate piece 600mm, perm. nose load 150kg, without hitch components, for wheel brake 3062 / 3081.
total length K (at 0°) 3916mm, drawbar length E 2610mm, drawbar section 80x140x4mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
rim size 5.50x14, hole number 5, rim centre hole Ø 67mm, bolt circle 112mm, offset +30, radial, tyre 185 R 14 C, load index 104N, load capacity 900kg at 140km/h.
build design radial, tyre size 165/70 R 13, TL (tubeless), load index 84, speed index N, tread AW-414, specification M+S, load capacity 500kg at 140km/h, inflation pressure 2.7 bar.
tyre size 5.00-10, TL (tubeless), load index 79, speed index M, tread K364, specification E-mark, load capacity 437kg at 130km/h, inflation pressure 3.4 bar.
build design radial, tyre size 205 R 14, TL (tubeless), load index 109/107, speed index P, tread MAXMILER PRO, load capacity 1030kg at 150km/h, inflation pressure 4.5 bar.
build design radial, tyre size 195/70 R 14, TL (tubeless), load index 96, speed index N, tread KargoMax ST-4000, specification M+S, load capacity 710kg at 140km/h, inflation pressure 3.1 bar.
build design radial, tyre size 145/80 R 13, TL (tubeless), load index 79, speed index N, tread KargoMax ST-4000 XL, specification M+S, load capacity 437kg at 140km/h, inflation pressure 3.0 bar.
build design radial, tyre size 165 R 13 C, TL (tubeless), load index 96, speed index N, tread KargoMax ST-6000, specification M+S, load capacity 710kg at 140km/h, inflation pressure 4.5 bar.
tyre size 5.70/5.00–8, TL (tubeless), load index 77, speed index M, tread S-378, specification E-mark, load capacity 412kg at 130km/h, inflation pressure 5.30 bar.
