total length K (at 0°) 3260mm, drawbar length E 2130mm, drawbar section 120x200mm, intermediate piece 750mm, perm. nose load 500kg, without hitch components.
total length K (at 0°) 3670mm, drawbar length E 2450mm, drawbar section 120x160mm, intermediate piece 750mm, perm. nose load 150kg, without hitch components.
total length K (at 0°) 3459mm, drawbar length E 2450mm, drawbar section 70x140x3mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 3609mm, drawbar length E 2600mm, drawbar section 70x70x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 3129mm, drawbar length E 2120mm, drawbar section 70x70x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 3859mm, drawbar length E 2850mm, drawbar section 70x110x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 3059mm, drawbar length E 2050mm, drawbar section 70x110x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 2659mm, drawbar length E 1650mm, drawbar section 70x110x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 2019mm, drawbar length E 1010mm, drawbar section 70x110x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
dimension A 2860mm, drawbar section 70x70x5mm, perm. nose load 75kg, coupling head type AK 7, inclusive skid bracket, clamping bracket and plug holder.
dimension A 2490mm, drawbar section 60x60x4mm, perm. nose load 75kg, coupling head type AK 7, inclusive skid bracket, clamping bracket and plug holder.
dimension A 2250mm, drawbar section 60x60x4mm, perm. nose load 75kg, coupling head type AK 7, inclusive skid bracket, clamping bracket and plug holder.
dimension A 2330mm, drawbar section 60x60x3mm, perm. nose load 75kg, coupling head type AK 7, inclusive skid bracket, clamping bracket and plug holder.
dimension A 1610mm, drawbar section 60x60x3mm, perm. nose load 75kg, coupling head type AK 7, inclusive skid bracket, clamping bracket and plug holder.
dimension A 5000mm, drawbar section 60x60x4mm, perm. nose load 75kg, coupling head type AK 7, inclusive skid bracket, clamping bracket and plug holder.
dimension A 3235mm, drawbar section 60x60x4mm, perm. nose load 75kg, coupling head type AK 7, inclusive skid bracket, clamping bracket and plug holder.
dimension A 2635mm, drawbar section 60x60x4mm, perm. nose load 75kg, coupling head type AK 7, inclusive skid bracket, clamping bracket and plug holder.
dimension A 2355mm, drawbar section 60x60x3mm, perm. nose load 75kg, coupling head type AK 7, inclusive skid bracket, clamping bracket and plug holder.
BC: dimension A 1125mm, OHF: dimension C 1630mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 30-33mm, swing arm position 25°, axle profile 97mm.
BC: dimension A 1450mm, OHF: dimension C 1960mm, wheel connection 100x4, wheel brake type 1637, offset (ET) 27-33mm, swing arm position 25°, axle profile 80mm.
