WINTERHOFF

WINTERHOFF

For decades, the name has been a constant on the market and fits perfectly into the AL-KO Vehicle Technology portfolio with its main focus on hitches, jockey wheels and fittings. The high Winterhoff quality is based on many years of experience, reliable employees, Modern manufacture and perfect quality management, and guarantees exceptional value for money.

Tailgate latch type BV 10-1 (replaced 1223610)
tensile strength 900 daN, matching mounting bracket BVG 10-A or BVG 10-B, TÜV North certificate extant, surface treatment galvanised.
Price 8,90 EUR Incl. tax Excl. Shipping costs
Mounting bracket type WVG 20-A
tensile strength 1200 daN, TÜV North certificate extant, surface treatment galvanised.
Price 6,90 EUR Incl. tax Excl. Shipping costs
Mounting bracket type WVG 10-A, packing unit 80 units
tensile strength 1000 daN, TÜV North certificate extant, surface treatment galvanised.
Price 205,00 EUR Incl. tax Excl. Shipping costs
Coupling head WW 350-RC
drawbar ⌀60mm round, holes (screw connection) cross 14.5mm, hole distance 40mm, perm. gross weight 3500kg, nose load 200kg, material: malleable cast iron.
Price 84,90 EUR Incl. tax Excl. Shipping costs
Disk lock loose 70mm
universally usable, with 2 keys.
Price 7,90 EUR Incl. tax Excl. Shipping costs
Hand crank type HKB SW 19-L920
length dimension X 920mm, dimension Y 580mm, wrench size 19, surface treatment galvanised.
Price 19,90 EUR Incl. tax Excl. Shipping costs
Steady leg 48mm round, ST 48-120
stationary nose load max. 150kg, length 725mm, stroke (extended length) 220mm, galvanised, top crank, long version.
Price 48,20 EUR Incl. tax Excl. Shipping costs
Steady leg, spindle 60x60mm square, pivoting 90° sideways, 1863474
stationary nose load max. 1300kg, length 590mm, stroke (extended length) 675mm, galvanised, side crank, long version, height adjustment.
Price 170,00 EUR Incl. tax Excl. Shipping costs
Steady leg, spindle 60x60mm square, pivoting 90° sideways, 1863473
stationary nose load max. 1300kg, length 590mm, stroke (extended length) 675mm, galvanised, push-on crank, long version, height adjustment.
Price 152,00 EUR Incl. tax Excl. Shipping costs
Solid rubber wheel 400x60mm 400 VBR
wheel 400x60mm solid rubber, rim steel, hub ø25x88mm, load when parked 500kg.
Price 129,10 EUR Incl. tax Excl. Shipping costs
Pneumatic wheel 260x85mm 260 LB
wheel 260x85mm air, rim steel, hub ø20x88mm, load when parked 200kg.
Price 47,70 EUR Incl. tax Excl. Shipping costs
Clamp ø60mm round KLE 60, rigid T-bar
stationary nose load max. 500kg, base plate steel, connection 10-hole.
Price 28,20 EUR Incl. tax Excl. Shipping costs
Clamp ø48mm round KLE 48-R, rigid T-bar
stationary nose load max. 250kg, base plate steel, crude, connection 2-hole.
Price 14,90 EUR Incl. tax Excl. Shipping costs
Clamp ø48mm round KLE 48-LK, rigid T-bar
stationary nose load max. 250kg, base plate steel, connection 2-hole.
Price 13,90 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø60mm round, type VK 60-ABLFH-255 SB, long version, support shoe fully automatic
stationary nose load max. 400kg, nose load when manoeuvring max.240kg, rim steel, wheel 225x70mm solid rubber, extended length 235 + 235mm.
Price 99,90 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø60mm round, type ST 60-V-255 SB, reinforced version
stationary nose load max. 400kg, nose load when manoeuvring max.240kg, rim steel, wheel 225x70mm solid rubber, extended length 230mm.
Price 116,80 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø48mm round, type ST 48-V-255 SB, reinforced version
stationary nose load max. 200kg, nose load when manoeuvring max.150kg, rim steel, wheel 225x70mm solid rubber, extended length 230mm.
Price 139,90 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø48mm round, type ST 48-200 V
stationary nose load max. 150kg, nose load when manoeuvring max.90kg, rim plastic, wheel 200x50mm solid rubber, extended length 220mm.
Price 24,90 EUR Incl. tax Excl. Shipping costs
Friction lining WS
suitable for WS3000 up to year of manufacture 07/2002.
Price 59,90 EUR Incl. tax Excl. Shipping costs
Coupling head WW 200-B5-H
drawbar ⌀50-51mm round, holes (screw connection) cross 12.5mm, hole distance 40mm, perm. gross weight 3000kg, nose load 150kg, material: malleable cast iron.
Price 114,80 EUR Incl. tax Excl. Shipping costs
Coupling head WW 8-D45 with holder
drawbar □ 45mm square, holes (screw connection) vertical 11mm, hole distance 90mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 47,70 EUR Incl. tax Excl. Shipping costs
Coupling head WW 8-D30
drawbar □ 30mm square, holes (screw connection) vertical 11mm, hole distance 90mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 45,90 EUR Incl. tax Excl. Shipping costs
Soft-Ball, black, without packaging
1 unit, for towing hitch with 50mm ball, colour black.
Price 10,90 EUR Incl. tax Excl. Shipping costs
Tailgate hinge type BSCH 10-17-320-TE, packing unit 50 units
surface treatment galvanised.
Price 319,00 EUR Incl. tax Excl. Shipping costs
