For decades, the name has been a constant on the market and fits perfectly into the AL-KO Vehicle Technology portfolio with its main focus on hitches, jockey wheels and fittings. The high Winterhoff quality is based on many years of experience, reliable employees, Modern manufacture and perfect quality management, and guarantees exceptional value for money.

Extendable corner steady ADS 480 for front left and rear right
stationary nose load max. 2000kg (bei 4 Stück), extended length 480mm, hot-dip galvanised, push-on crank.
Price 72,90 EUR Incl. tax Excl. Shipping costs
Coupling head WW 150-RB
drawbar ⌀50-51mm round, holes (screw connection) cross 12.5mm, hole distance 40mm, perm. gross weight 1500kg, nose load 100kg, material: steel.
Price 33,90 EUR Incl. tax Excl. Shipping costs
Tailgate latch lockable type BVS 60-1, 1 pair (single kex)
tensile strength 650 daN, matching mounting bracket BVSG 60-A, TÜV North certificate extant, surface treatment galvanised.
Price 22,90 EUR Incl. tax Excl. Shipping costs
Securing system for jockey wheel ø48mm, BS-KLE 48, 1860693
secures jockey wheel ST 48 while driving.
Price 15,80 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø48mm round, type ST 48-V-255 SB, reinforced version
stationary nose load max. 200kg, nose load when manoeuvring max.120kg, rim steel, wheel 225x70mm solid rubber, extended length 230mm.
Price 52,60 EUR Incl. tax Excl. Shipping costs
Steady leg, spindle □60mm square, pivoting sideways, SF 60-19-400
stationary nose load max. 1300kg, length 535mm, stroke (extended length) 365mm, galvanised, push-on crank.
Price 84,90 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø48mm round, type ST 48-CW-260 LB, with integrated wheel load indicator
stationary nose load max. 150kg, nose load when manoeuvring max.90kg, rim steel, wheel 260x85mm air, extended length 220mm.
Price 116,60 EUR Incl. tax Excl. Shipping costs
Special coupling head WW 300-H only suitable for ø60mm balls
drawbar ⌀50mm round, holes (screw connection) cross, horizontal 14.5mm, vertical 12.5mm, hole distance 40mm, perm. gross weight 3500kg, nose load 150kg, material: malleable cast iron.
Price 265,60 EUR Incl. tax Excl. Shipping costs
Steady leg, spindle 60x60mm square, pivoting 90° sideways, 1863474
stationary nose load max. 1300kg, length 590mm, stroke (extended length) 675mm, galvanised, side crank, long version, height adjustment.
Price 166,30 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø48mm round, type ST 48-CW-240 S, with integrated wheel load indicator
stationary nose load max. 150kg, nose load when manoeuvring max.90kg, rim plastic, wheel 215x70mm rubber, extended length 220mm.
Price 118,40 EUR Incl. tax Excl. Shipping costs
Coupling head WW 8-E with holder
drawbar □ 50mm square, holes (screw connection) vertical 11mm, hole distance 90mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 34,90 EUR Incl. tax Excl. Shipping costs
Binder support □70mm round square, KBFV 70
stationary nose load max. 250kg.
Price 7,60 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø48mm round, type ST 48-CW-255 SB, with integrated wheel load indicator
stationary nose load max. 150kg, nose load when manoeuvring max.90kg, rim steel, wheel 225x70mm solid rubber, extended length 220mm.
Price 126,10 EUR Incl. tax Excl. Shipping costs
Coupling head WW 8-G
drawbar □ 60mm square, holes (screw connection) vertical 11mm, hole distance 90mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 26,10 EUR Incl. tax Excl. Shipping costs
Tailgate latch type BV 20-3
tensile strength 900 daN, matching mounting bracket BVG 20-A or BVG 20-B, TÜV North certificate extant, surface treatment galvanised.
Price 9,50 EUR Incl. tax Excl. Shipping costs
Tailgate latch type BV 10-1 (replaced 1223610)
tensile strength 900 daN, matching mounting bracket BVG 10-A or BVG 10-B, TÜV North certificate extant, surface treatment galvanised.
Price 6,90 EUR Incl. tax Excl. Shipping costs
Steady leg, spindle 60x60mm square, pivoting 90° sideways, 1863473
stationary nose load max. 1300kg, length 590mm, stroke (extended length) 675mm, galvanised, push-on crank, long version, height adjustment.
Price 148,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation with coupling head WW 8-E, V-adapter and holder, top installation
holes (screw connection) vertical 14mm, hole distance 131/166/120/218mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 97,00 EUR Incl. tax Excl. Shipping costs
Coupling head WW 8-D45 with holder
drawbar □ 45mm square, holes (screw connection) vertical 11mm, hole distance 90mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 47,70 EUR Incl. tax Excl. Shipping costs
Coupling type KUB 50-2000kg
thread M20x1.5, trailer load 2000kg, ball diam.Ø 50mm, D/Dc value 18.5 kN.
Price 27,90 EUR Incl. tax Excl. Shipping costs
Tailgate hinge type BSCH 30-2
surface treatment galvanised.
Price 6,50 EUR Incl. tax Excl. Shipping costs
Tailgate hinge type BSCH 10-17-170
matching mounting bracket BSCHG 10-17-A, BSCHG 10-17-B, BSCHG 10-17-B without Bolzen or BSCHG 10-17-C, surface treatment galvanised.
Price 6,20 EUR Incl. tax Excl. Shipping costs
Steady leg, spindle □60mm square, pivoting sideways, SF 60-19-280
stationary nose load max. 1300kg, length 415mm, stroke (extended length) 240mm, galvanised, push-on crank.
Price 96,90 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø60mm round, type VK 60-BLH-255 SB, long version, support shoe fully automatic
stationary nose load max. 500kg, nose load when manoeuvring max.300kg, rim steel, wheel 225x70mm solid rubber, extended length 235 + 235mm.
Price 133,20 EUR Incl. tax Excl. Shipping costs
