For decades, the name has been a constant on the market and fits perfectly into the AL-KO Vehicle Technology portfolio with its main focus on hitches, jockey wheels and fittings. The high Winterhoff quality is based on many years of experience, reliable employees, Modern manufacture and perfect quality management, and guarantees exceptional value for money.

Tailgate latch type BV 10-1-2
tensile strength 900 daN, matching mounting bracket BVG 10-A or BVG 10-B, TĂśV North certificate extant, surface treatment galvanised.
Price 8,90 EUR Incl. tax Excl. Shipping costs
Coupling head WS 3500-D 60 with anti-sway damping
drawbar ⌀60mm round, holes (screw connection) cross 16.5mm, hole distance 54mm, perm. gross weight 3500kg, nose load 150kg, material: malleable cast iron, tightening torque 90 Nm.
Price 499,90 EUR Incl. tax Excl. Shipping costs
Rigid steady leg 48mm round, RSR 480-700
stationary nose load max. 150kg, length 750mm, galvanised, long version.
Price 19,40 EUR Incl. tax Excl. Shipping costs
Steady leg, spindle 60x60mm square, pivoting 90° sideways, 1863474
stationary nose load max. 1300kg, length 590mm, stroke (extended length) 675mm, galvanised, side crank, long version, height adjustment.
Price 170,00 EUR Incl. tax Excl. Shipping costs
Loose crank, 1860629
for jockey wheel.
Price 13,90 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø70mm round, type K 70-400 VBR, support shoe semi-automatic
stationary nose load max. 600kg, nose load when manoeuvring max.360kg, rim steel, wheel 400x75mm solid rubber, extended length 330 + 220mm.
Price 449,50 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø60mm round, type VK 60-BH-255 SB, support shoe fully automatic
stationary nose load max. 350kg, nose load when manoeuvring max.210kg, rim steel, wheel 225x70mm solid rubber, extended length 235 + 235mm.
Price 99,10 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø60mm round, type ST 60-V-255 VB, reinforced version
stationary nose load max. 500kg, nose load when manoeuvring max.300kg, rim steel, wheel 225x80mm solid rubber, extended length 230mm.
Price 86,50 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø48mm round, type ST 48-C-240 S
stationary nose load max. 150kg, nose load when manoeuvring max.90kg, rim plastic, wheel 215x70mm rubber, extended length 220mm.
Price 49,90 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø48mm round, type ST 48-255 S
stationary nose load max. 150kg, nose load when manoeuvring max.90kg, rim plastic, wheel 225x70mm solid rubber, extended length 210mm.
Price 52,80 EUR Incl. tax Excl. Shipping costs
Coupling head WS 3000-D 50 with anti-sway damping
drawbar ⌀50mm round, holes (screw connection) cross 14.5mm, hole distance 40mm, perm. gross weight 3000kg, nose load 150kg, material: malleable cast iron, tightening torque 90 Nm.
Price 555,90 EUR Incl. tax Excl. Shipping costs
Coupling head WS 3000-D 50 with anti-sway damping
drawbar ⌀35/40/45/46/50mm round, holes (screw connection) cross 12.5mm, hole distance 40-54mm, perm. gross weight 3000kg, nose load 150kg, material: malleable cast iron, tightening torque 90 Nm.
Price 399,90 EUR Incl. tax Excl. Shipping costs
Coupling head WW 350-RD
drawbar ⌀65mm round, holes (screw connection) cross 14.5mm, hole distance 40mm, perm. gross weight 3500kg, nose load 200kg, material: malleable cast iron.
Price 84,90 EUR Incl. tax Excl. Shipping costs
Coupling head WW 8-E with holder
drawbar â–ˇ 50mm square, holes (screw connection) vertical 11mm, hole distance 90mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 34,90 EUR Incl. tax Excl. Shipping costs
Coupling head WW 8-D30
drawbar â–ˇ 30mm square, holes (screw connection) vertical 11mm, hole distance 90mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 38,10 EUR Incl. tax Excl. Shipping costs
Coupling head WW 8-C
drawbar ⌀70mm round, holes (screw connection) vertical 11mm, hole distance 90mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 28,40 EUR Incl. tax Excl. Shipping costs
Skid bracket for unbraked tubular drawbars, 1860680
A skid bracket protects the hitch against contamination from ground contact.
Price 6,90 EUR Incl. tax Excl. Shipping costs
Tailgate hinge type BSCH 10-17-170-SO
matching mounting bracket BSCHG 10-17-A, BSCHG 10-17-B, BSCHG 10-17-B without Bolzen or BSCHG 10-17-C, surface treatment galvanised.
Price 8,90 EUR Incl. tax Excl. Shipping costs
Tailgate hinge type BSCH 10-17-170
matching mounting bracket BSCHG 10-17-A, BSCHG 10-17-B, BSCHG 10-17-B without Bolzen or BSCHG 10-17-C, surface treatment galvanised.
Price 8,90 EUR Incl. tax Excl. Shipping costs
Mounting bracket tailgate hinge type BSCHG 40-A, packing unit 60 units
surface treatment galvanised.
Price 274,00 EUR Incl. tax Excl. Shipping costs
Mounting bracket tailgate hinge type BSCHG 10-17-A
surface treatment galvanised.
Price 5,90 EUR Incl. tax Excl. Shipping costs
Mounting bracket tailgate latch type BVG 20-B
tensile strength 450 daN, TĂśV North certificate extant, surface treatment galvanised.
Price 4,90 EUR Incl. tax Excl. Shipping costs
Mounting bracket tailgate latch type BVG 20-A, packing unit 90 units
tensile strength 450 daN, TĂśV North certificate extant, surface treatment galvanised.
Price 165,00 EUR Incl. tax Excl. Shipping costs
Lashing type ZBF 70-1, packing unit 50 units
tensile strength 800 daN, TĂśV North certificate extant, surface treatment galvanised.
Price 274,00 EUR Incl. tax Excl. Shipping costs
