WINTERHOFF

WINTERHOFF

For decades, the name has been a constant on the market and fits perfectly into the AL-KO Vehicle Technology portfolio with its main focus on hitches, jockey wheels and fittings. The high Winterhoff quality is based on many years of experience, reliable employees, Modern manufacture and perfect quality management, and guarantees exceptional value for money.

Kit cover cap black
suitable for WS3000 up to year of manufacture 07/2002.
Price 15,90 EUR Incl. tax Excl. Shipping costs
Coupling head WS 3000-D 50 with anti-sway damping
drawbar ⌀50mm round, holes (screw connection) cross, horizontal 14.5mm, vertical 12.5mm, hole distance 40mm, perm. gross weight 3000kg, nose load 150kg, material: malleable cast iron, tightening torque 90 Nm.
Price 573,40 EUR Incl. tax Excl. Shipping costs
Coupling head WW 20-F2
drawbar ⌀70mm round, holes (screw connection) vertical 12.5mm, hole distance 90/116mm, perm. gross weight 2000kg, nose load 100kg, material: malleable cast iron.
Price 106,00 EUR Incl. tax Excl. Shipping costs
Coupling head WW 150-VG
drawbar □70mm square, holes (screw connection) vertical 12.5mm, hole distance 90mm, perm. gross weight 1500kg, nose load 100kg, material: steel.
Price 45,90 EUR Incl. tax Excl. Shipping costs
Coupling head WW 150-VF
drawbar □60mm square, holes (screw connection) vertical 12.5mm, hole distance 90mm, perm. gross weight 1500kg, nose load 100kg, material: steel.
Price 44,50 EUR Incl. tax Excl. Shipping costs
Coupling head WW 8-Y with holder
drawbar V 34°, holes (screw connection) horizontal 12.5mm, hole distance 40mm, holes (screw connection) vertical 13mm, hole distance 50mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 69,00 EUR Incl. tax Excl. Shipping costs
Coupling head WW 8-D40
drawbar □ 40mm square, holes (screw connection) vertical 11mm, hole distance 90mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 33,90 EUR Incl. tax Excl. Shipping costs
Tailgate hinge type BSCH 10-270-SO
matching mounting bracket BSCHG 10-17-A, BSCHG 10-17-B, BSCHG 10-17-B without Bolzen or BSCHG 10-17-C, surface treatment galvanised.
Price 9,90 EUR Incl. tax Excl. Shipping costs
Locking pin type BSCHG 20-A, packing unit 60 units
surface treatment galvanised.
Price 405,00 EUR Incl. tax Excl. Shipping costs
Lashing type ZBF 70-2
tensile strength 800 daN, TÜV North certificate extant, surface treatment galvanised.
Price 9,90 EUR Incl. tax Excl. Shipping costs
Lashing type ZBF 50-1
tensile strength 240 daN, TÜV North certificate extant, surface treatment galvanised.
Price 4,90 EUR Incl. tax Excl. Shipping costs
Tailgate latch type BV 10-1-2, packing unit 60 units
tensile strength 900 daN, matching mounting bracket BVG 10-A or BVG 10-B, TÜV North certificate extant, surface treatment galvanised.
Price 318,00 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø70mm round, type ST 70-L-250 VAR
stationary nose load max. 900kg, nose load when manoeuvring max.540kg, rim steel, wheel 250x80mm solid rubber, extended length 370mm.
Price 690,90 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø48mm round, type ST 48-200 VB
stationary nose load max. 150kg, nose load when manoeuvring max.90kg, rim steel, wheel 200x50mm solid rubber, extended length 220mm.
Price 26,90 EUR Incl. tax Excl. Shipping costs
Jockey wheel ø35mm round, type ST 35-160 V
stationary nose load max. 75kg, nose load when manoeuvring max.45kg, rim plastic, wheel 160x40mm solid rubber, extended length 220mm.
Price 34,10 EUR Incl. tax Excl. Shipping costs
Soft Dock WS
colour blue, suitable for WS3000 from year of manufacture 08/2009.
Price 49,90 EUR Incl. tax Excl. Shipping costs
Kit cover cap (angle) WS
suitable for WS3000 up to year of manufacture 07/2002.
Price 21,50 EUR Incl. tax Excl. Shipping costs
7-13 pin plug holder sheet metal
for coupling heads, universally usable.
Price 3,50 EUR Incl. tax Excl. Shipping costs
Coupling head WW 30-D3
drawbar ⌀50-51mm round, holes (screw connection) cross 14.5mm, hole distance 40mm, perm. gross weight 3000kg, nose load 150kg, material: malleable cast iron.
Price 79,90 EUR Incl. tax Excl. Shipping costs
Coupling head WW 200-C7-H
drawbar ⌀70mm round, holes (screw connection) vertical 12.5mm, hole distance 90/116mm, perm. gross weight 3000kg, nose load 150kg, material: malleable cast iron.
Price 131,50 EUR Incl. tax Excl. Shipping costs
Coupling head WW 150-VG with holder
drawbar □70mm square, holes (screw connection) vertical 12.5mm, hole distance 90mm, perm. gross weight 1500kg, nose load 100kg, material: steel.
Price 49,90 EUR Incl. tax Excl. Shipping costs
Coupling head WW 8-E
drawbar □ 50mm square, holes (screw connection) cross 11mm, hole distance 80-90mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 39,90 EUR Incl. tax Excl. Shipping costs
Coupling head WW 8-H with holder
drawbar □ 70mm square, holes (screw connection) vertical 11mm, hole distance 90mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 41,90 EUR Incl. tax Excl. Shipping costs
Coupling head WW 8-B with holder
drawbar ⌀60mm round, holes (screw connection) vertical 11mm, hole distance 90mm, perm. gross weight 800kg, nose load 75kg, material: steel.
Price 29,90 EUR Incl. tax Excl. Shipping costs
