RUNNING WELL FOR YOU. BPW BERGISCHE AXLES

AL-KO Technology Paderborn GmbH specialises in the development and manufacture of complete running gear technology for car trailers and self-propelled vehicles. The location has developed from a labour-intensive wagon maker into an innovative, modern industrial company. Since 2017 the former BPW Fahrzeugtechnik has been part of the global technology company DexKo Global Inc., a worldwide market leader for trailer axles and chassis components in the lightweight segment. Read more...

Underpinning Your Progress.
The range of running gear for towable machinery, car and light truck trailers, caravans and cab & engine vehicles.



Cable conduit support / tandem adapter bracket
BPW (AL-KO) Cable conduit support / tandem adapter bracket
for attachment to the axle, dimension K (axle tube) square 80mm
Price 111,40 EUR Incl. tax Excl. Shipping costs
Coupling head WW 30-D6
BPW (AL-KO) Coupling head WW 30-D6
for drawbar connection 60mm round, screw connection cross 12.5mm, hole distance 40mm, perm. gross weight 3000kg, nose load 150kg, material: malleable cast iron.
Price 272,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZKV 25.1 D with overrun device AK 3510 B height-adjustable, with drawbar section 1910 to 2700kg, 47.43.471.012
BPW (AL-KO) Drawbar installation ZKV 25.1 D with overrun device AK 3510 B height-adjustable, with drawbar section 1910 to 2700kg, 47.43.471.012
drawbar length L 2500mm, FD at max. 2700kg: 2453mm, drawbar section K square 120x6.3mm, spacer V 680mm, perm. nose load 150kg, with coupling head EM 350 R-D-K1212, for wheel brake S 2005-7 and S 2504-7.
Price 3.900,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 1.6-1 with overrun device ZAAQ1.6 / ZDG7-3 drawbar section straight 800 to 1600kg, 48.29.181.055
BPW (AL-KO) Drawbar installation ZAAR 1.6-1 with overrun device ZAAQ1.6 / ZDG7-3 drawbar section straight 800 to 1600kg, 48.29.181.055
drawbar length L 2100mm, FD at max. 1600kg: 1200mm, drawbar section K square 70x5.0mm, measure HA 50mm, thread G M10, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 637,50 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAA 1.3-1.1 with overrun device AK 1308 and removable drawbar section from 650 to 1300kg, 47.24.181.004
BPW (AL-KO) Drawbar installation ZAA 1.3-1.1 with overrun device AK 1308 and removable drawbar section from 650 to 1300kg, 47.24.181.004
drawbar length L 2500mm, length A 1100mm, drawbar section K 88.9x5.6mm, thread G M10, perm. nose load 100kg, with coupling head EM 150 R-B, for wheel brake S 1704-7 and S 2005-7.
Price 1.601,90 EUR Incl. tax Excl. Shipping costs
Drawbar eye DIN 40.0-01
BPW (AL-KO) Drawbar eye DIN 40.0-01
dimension K 40.8mm, dimension S 40mm, dimension L 200mm, EG e1 0347 94/20, nose load 100kg, perm. gross weight 2000kg, suitable for types ZAA 1.3-1, 2.0-1, ZKV 13/20 and ZRV 13/20.
Price 233,80 EUR Incl. tax Excl. Shipping costs
Drawbar shaft strap for ZEA drawbars, distance 100mm
BPW (AL-KO) Drawbar shaft strap for ZEA drawbars, distance 100mm
for installation of towbar connection parts, suitable for types ZAF and ZOF.
Price 14,90 EUR Incl. tax Excl. Shipping costs
Horizontal bolts
BPW (AL-KO) Horizontal bolts
mounting part kit, screw connection kit for ZEA drawbars.
Price 64,20 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 5.0-1.1 height-adjustable with drawbar section up to 5000kg, 47.62.403.003
BPW (AL-KO) Towbar connection ZOV 5.0-1.1 height-adjustable with drawbar section up to 5000kg, 47.62.403.003
drawbar length L 3000mm, drawbar section K 127mm, with DIN drawbar eye dimension A 716mm, height B 0-413mm, intermediate piece V 550mm, perm. nose load 400kg.
Price 2.187,90 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.015
BPW (AL-KO) Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.015
drawbar length L 2090mm, drawbar section K 108/90mm, with DIN drawbar eye dimension A 635mm, height B 0-375mm, intermediate piece V 500mm, perm. nose load 150kg.
Price 1.466,60 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.013
BPW (AL-KO) Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.013
drawbar length L 2090mm, drawbar section K 108/90mm, with DIN drawbar eye dimension A 568mm, height B 0-300mm, intermediate piece V 400mm, perm. nose load 150kg.
Price 1.444,10 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.006
BPW (AL-KO) Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.006
drawbar length L 1590mm, drawbar section K 108/90mm, with DIN drawbar eye dimension A 501mm, height B 0-225mm, intermediate piece V 300mm, perm. nose load 150kg.
Price 1.229,90 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.001
BPW (AL-KO) Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.001
drawbar length L 1090mm, drawbar section K 108/90mm, with DIN drawbar eye dimension A 501mm, height B 0-225mm, intermediate piece V 300mm, perm. nose load 150kg.
Price 1.218,70 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 1.2-1.1 B height-adjustable with drawbar section up to 1200kg, 47.23.403.012
BPW (AL-KO) Towbar connection ZOV 1.2-1.1 B height-adjustable with drawbar section up to 1200kg, 47.23.403.012
drawbar length L 1070mm, drawbar section K 82.5mm, with DIN drawbar eye dimension A 589mm, height B 0-300mm, intermediate piece V 400mm, perm. nose load 100kg.
Price 859,90 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 0.75-1 B height-adjustable with drawbar section up to 750kg, 47.14.401.002
BPW (AL-KO) Towbar connection ZOV 0.75-1 B height-adjustable with drawbar section up to 750kg, 47.14.401.002
drawbar length L 1075mm, drawbar section K 70mm, with coupling head dimension A 675mm, height B 0-375mm, intermediate piece V 500mm, perm. nose load 75kg.
Price 715,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZOF 0,75-1 with coupling head EM 80, 48.14.501.001
BPW (AL-KO) Drawbar installation ZOF 0,75-1 with coupling head EM 80, 48.14.501.001
dimension FH 190-210mm, dimension FV 100-110mm, dimension H 25mm, dimension S 13mm, perm. gross weight 750kg, nose load 75kg (see technical drawing)
Price 70,90 EUR Incl. tax Excl. Shipping costs
Stopper
BPW (AL-KO) Stopper
can be used with wheel brake S 2005-5 RASK.
Price 8,10 EUR Incl. tax Excl. Shipping costs
Original taper-head wheel bolt M12x1.5
BPW (AL-KO) Original taper-head wheel bolt M12x1.5
thread 24mm, wrench size AF 19, bolt quality 8.8, maximum permitted tightening torque 90 Nm.
Price 3,90 EUR Incl. tax Excl. Shipping costs
Brake shoes, wheel brake S 2504-5 RASK, brake size 250x40mm
BPW (AL-KO) Brake shoes, wheel brake S 2504-5 RASK, brake size 250x40mm
consisting of brake shoes, pressure springs, tension springs, spring support, for one axle (2 wheel brakes left + right).
Price 250,00 EUR Incl. tax Excl. Shipping costs
Brake shoes, wheel brake S 2005-5 RASK, brake size 200x50mm
BPW (AL-KO) Brake shoes, wheel brake S 2005-5 RASK, brake size 200x50mm
consisting of brake shoes, pressure springs, tension springs, spring support, clamping screw, adjustment wedges, for one axle (2 wheel brakes left + right).
Price 427,10 EUR Incl. tax Excl. Shipping costs
Braked axle 1800kg SWING axle type CB 1805, 46.32.368.500
BPW (AL-KO) Braked axle 1800kg SWING axle type CB 1805, 46.32.368.500
BC: dimension AM 900mm, OHF: dimension FL 1735mm, wheel connection 112x5, wheel brake type S 2504-7 RASK, offset (ET) 35mm, swing arm position 20°, axle profile 95mm, ball-head wheel bolts M12x1.5.
Price 1.750,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1500kg axle type CB 1505, 44.27.379.607 - Weinsberg 550 QDK
BPW (AL-KO) Braked axle 1500kg axle type CB 1505, 44.27.379.607 - Weinsberg 550 QDK
BC: dimension AM 1676mm, OHF: dimension FL 2260mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm.
Price 1.480,00 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 3.0-3, 1800 to 3000kg, 1804384, 1731585
BPW (AL-KO) Overrun device V type ZAF 3.0-3, 1800 to 3000kg, 1804384, 1731585
connection 167mm, nose load 150kg, drawbar installation version top + bottom, combined with BPW wheel brake S2005-7, S2504-7 and S3006-7 RASK, with coupling head AKS 3004.
Price 695,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1350kg axle type CB 1355
BPW (AL-KO) Braked axle 1350kg axle type CB 1355
BC: dimension AM 1550mm, OHF: dimension FL 2070mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 95mm.
Price 1.215,00 EUR Incl. tax Excl. Shipping costs
