RUNNING WELL FOR YOU. BPW BERGISCHE AXLES

AL-KO Technology Paderborn GmbH specialises in the development and manufacture of complete running gear technology for car trailers and self-propelled vehicles. The location has developed from a labour-intensive wagon maker into an innovative, modern industrial company. Since 2017 the former BPW Fahrzeugtechnik has been part of the global technology company DexKo Global Inc., a worldwide market leader for trailer axles and chassis components in the lightweight segment. Read more...

Underpinning Your Progress.
The range of running gear for towable machinery, car and light truck trailers, caravans and cab & engine vehicles.



Drawbar installation ZAAR 1.6-1 with overrun device ZAAQ1.6 / ZDG7-3 drawbar section straight 800 to 1600kg, 48.29.181.056
BPW (AL-KO) Drawbar installation ZAAR 1.6-1 with overrun device ZAAQ1.6 / ZDG7-3 drawbar section straight 800 to 1600kg, 48.29.181.056
drawbar length L 2300mm, FD at max. 1600kg: 1200mm, drawbar section K square 70x5.0mm, measure HA 50mm, thread G M10, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 650,70 EUR Incl. tax Excl. Shipping costs
Drawbar eye Italy 45.0-02
BPW (AL-KO) Drawbar eye Italy 45.0-02
dimension K 51.8mm, dimension S 45mm, dimension L 115mm, EG e1 1149 94/20, nose load 150kg, perm. gross weight 3500kg, suitable for types ZAA 3.5-1, ZKV 25/35 and ZAV 3.5-1.
Price 386,90 EUR Incl. tax Excl. Shipping costs
Drawbar eye NATO 76.0-02
BPW (AL-KO) Drawbar eye NATO 76.0-02
dimension K 51.8mm, dimension S 76mm, dimension L 95mm, EG e1 0642 94/20 / ECE test code E1 55R-01 0642, nose load 150kg, perm. gross weight 3500kg, suitable for types ZAA 3.5-1, ZKV 25/35 and ZAV 3.5-1.
Price 550,00 EUR Incl. tax Excl. Shipping costs
Towbar connection (pair) ZEA 3.5-1.1 to 3500kg, 05.447.26.21.1
BPW (AL-KO) Towbar connection (pair) ZEA 3.5-1.1 to 3500kg, 05.447.26.21.1
total length GL 2150mm, nose load 150kg.
Price 346,30 EUR Incl. tax Excl. Shipping costs
Towbar connection (pair) ZEA 2.8-1.1 B to 2800kg, 05.447.26.18.1
BPW (AL-KO) Towbar connection (pair) ZEA 2.8-1.1 B to 2800kg, 05.447.26.18.1
total length GL 2150mm, nose load 150kg.
Price 346,30 EUR Incl. tax Excl. Shipping costs
Towbar connection (pair) ZEA 2.0-1.1 to 2000kg, 05.447.26.24.1
BPW (AL-KO) Towbar connection (pair) ZEA 2.0-1.1 to 2000kg, 05.447.26.24.1
total length GL 2150mm, nose load 150kg.
Price 265,60 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 5.0-1.1 height-adjustable with drawbar section up to 5000kg, 47.62.403.002
BPW (AL-KO) Towbar connection ZOV 5.0-1.1 height-adjustable with drawbar section up to 5000kg, 47.62.403.002
drawbar length L 2500mm, drawbar section K 127mm, with DIN drawbar eye dimension A 716mm, height B 0-413mm, intermediate piece V 550mm, perm. nose load 400kg.
Price 2.052,60 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.005
BPW (AL-KO) Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.005
drawbar length L 1090mm, drawbar section K 108/90mm, with DIN drawbar eye dimension A 635mm, height B 0-375mm, intermediate piece V 500mm, perm. nose load 150kg.
Price 1.263,80 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 1.2-1.1 B height-adjustable with drawbar section up to 1200kg, 47.23.403.020
BPW (AL-KO) Towbar connection ZOV 1.2-1.1 B height-adjustable with drawbar section up to 1200kg, 47.23.403.020
drawbar length L 2070mm, drawbar section K 82.5mm, with DIN drawbar eye dimension A 523mm, height B 0-225mm, intermediate piece V 300mm, perm. nose load 100kg.
Price 919,90 EUR Incl. tax Excl. Shipping costs
Drawbar ZOR 0,75-1 A round tube straight up to 750kg, 48.14.101.012
BPW (AL-KO) Drawbar ZOR 0,75-1 A round tube straight up to 750kg, 48.14.101.012
total length L 2400mm, drawbar section K dimension K 70x4mm, perm. nose load 75kg, coupling head EM 80 R-GK, including skid bracket, clamping bracket and plug holder.
Price 274,90 EUR Incl. tax Excl. Shipping costs
Drawbar ZOR 0,75-1 A round tube straight up to 750kg, 48.14.101.010
BPW (AL-KO) Drawbar ZOR 0,75-1 A round tube straight up to 750kg, 48.14.101.010
total length L 2000mm, drawbar section K dimension K 70x4mm, perm. nose load 75kg, coupling head EM 80 R-GK, including skid bracket, clamping bracket and plug holder.
Price 253,90 EUR Incl. tax Excl. Shipping costs
Original ball-head wheel bolt M12x1.5, set of 8 pieces
BPW (AL-KO) Original ball-head wheel bolt M12x1.5, set of 8 pieces
thread 25mm, wrench size AF 19, bolt quality 8.8, maximum permitted tightening torque 90 Nm.
Price 16,90 EUR Incl. tax Excl. Shipping costs
Original ball-head wheel bolt M12x1.5
BPW (AL-KO) Original ball-head wheel bolt M12x1.5
thread 25mm, wrench size AF 19, bolt quality 8.8, maximum permitted tightening torque 90 Nm.
Price 3,90 EUR Incl. tax Excl. Shipping costs
2x Brake shoes, wheel brake S 3006-5 SK, brake size 300x60mm
BPW (AL-KO) 2x Brake shoes, wheel brake S 3006-5 SK, brake size 300x60mm
consisting of brake shoes, pressure springs, tension springs, spring support, for one axle (2 wheel brakes left + right).
Price 1.199,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1350kg / 1400kg axle type DB 1355, 45.25.379.548
BPW (AL-KO) Braked axle 1350kg / 1400kg axle type DB 1355, 45.25.379.548
BC: dimension AM 1540mm, OHF: dimension FL 2009mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 70mm, ball-head wheel bolts M12x1.5.
Price 1.300,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1500kg axle type CB 1505, 46.27.379.675
BPW (AL-KO) Braked axle SWING 1500kg axle type CB 1505, 46.27.379.675
BC: dimension AM 1600mm, OHF: dimension FL 2010mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 27-35mm, swing arm position 20°, axle profile 80mm.
Price 755,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1350kg axle type CB 1354, 46.24.379.421
BPW (AL-KO) Braked axle SWING 1350kg axle type CB 1354, 46.24.379.421
BC: dimension AM 750mm, OHF: dimension FL 1190mm, wheel connection 100x4, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm.
Price 580,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1800kg axle type CB1805, 46.32.368.173, Moetefindt
BPW (AL-KO) Braked axle SWING 1800kg axle type CB1805, 46.32.368.173, Moetefindt
BC: dimension AM 1420mm, OHF: dimension FL 1885mm, wheel connection 112x5, wheel brake type S 2504-7 RASK, offset (ET) 30mm, swing arm position 20°.
Price 1.250,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1800kg axle type SCB 1505, 46.27.379.921
BPW (AL-KO) Braked axle 1800kg axle type SCB 1505, 46.27.379.921
BC: dimension AM 1420mm, OHF: dimension FL 2070mm, wheel connection 112x5, wheel brake type S 2504-7 RASK, offset (ET) 30mm, swing arm position 15°, axle profile 95mm, ball-head wheel bolts M12x1.5.
Price 1.600,00 EUR Incl. tax Excl. Shipping costs
Shock absorber, Ausführung mit einem Auge
BPW (AL-KO) Shock absorber, Ausführung mit einem Auge
suitable for overrun devices ZAV 1.6-1, label old 05.323.60.02.0.
Price 139,90 EUR Incl. tax Excl. Shipping costs
Shock absorber, Ausführung mit zwei Augen
BPW (AL-KO) Shock absorber, Ausführung mit zwei Augen
suitable for overrun devices PAV/SR 0.7 A-S, label old 10.30.972041.
Price 119,90 EUR Incl. tax Excl. Shipping costs
Shock absorber, Ausführung mit zwei Augen
BPW (AL-KO) Shock absorber, Ausführung mit zwei Augen
suitable for overrun devices ZAAQ 3.0-3, ZAF 2.8-2 and ZAF 3.0-3, label old 02.3722.80.00, new 4018351.
Price 134,90 EUR Incl. tax Excl. Shipping costs
Shock absorber, version with two eyes
BPW (AL-KO) Shock absorber, version with two eyes
suitable for overrun devices ZAAQ 1.6-3, ZAF 1.35-3, ZAF 1.5-2 and ZAF 1.6-3, label old 02.3722.75.00, new 4014932.
Price 69,90 EUR Incl. tax Excl. Shipping costs
Shock absorber, Ausführung mit zwei Augen
BPW (AL-KO) Shock absorber, Ausführung mit zwei Augen
suitable for overrun devices ZAA 3.5-1, ZAA 3.5-1.1, ZAF 3.5-1, ZAF 3.5-3, ZAS 2.7-1, ZAS 3.5-1, ZKV 35 - AK3510A and ZRG 35.1, label old 02.3702.65.00, new 4014878.
Price 84,90 EUR Incl. tax Excl. Shipping costs
