RUNNING WELL FOR YOU. BPW BERGISCHE AXLES

AL-KO Technology Paderborn GmbH specialises in the development and manufacture of complete running gear technology for car trailers and self-propelled vehicles. The location has developed from a labour-intensive wagon maker into an innovative, modern industrial company. Since 2017 the former BPW Fahrzeugtechnik has been part of the global technology company DexKo Global Inc., a worldwide market leader for trailer axles and chassis components in the lightweight segment. Read more...

Underpinning Your Progress.
The range of running gear for towable machinery, car and light truck trailers, caravans and cab & engine vehicles.



Drawbar installation ZAV 1.6-5 with overrun device AE 2.7-1 D height-adjustable, with drawbar section 1200 to 1600kg, 47.29.470.061
BPW (AL-KO) Drawbar installation ZAV 1.6-5 with overrun device AE 2.7-1 D height-adjustable, with drawbar section 1200 to 1600kg, 47.29.470.061
drawbar length L 2800mm, measure B 0-520mm, FD at max. 1600kg: 3000mm, drawbar section K square 120mm, spacer V 600mm, perm. nose load 150kg, without hitch components, for wheel brake S 1704-7 and S 2005-7.
Price 2.558,40 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZKV 20.1 B with overrun device AK 2008 height-adjustable, with drawbar section cranked 1300 to 2000kg, 47.36.473.032
BPW (AL-KO) Drawbar installation ZKV 20.1 B with overrun device AK 2008 height-adjustable, with drawbar section cranked 1300 to 2000kg, 47.36.473.032
drawbar length L 2500mm, FD at max. 2000kg: 1526mm, drawbar section K round 101.6x10mm, spacer V 415mm, perm. nose load 100kg, with drawbar eye DIN 40.0-01, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 2.499,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZKV 13.1 A with overrun device AK 1308 height-adjustable, with drawbar section cranked 650 to 1300kg, 47.24.473.113
BPW (AL-KO) Drawbar installation ZKV 13.1 A with overrun device AK 1308 height-adjustable, with drawbar section cranked 650 to 1300kg, 47.24.473.113
drawbar length L 2100mm, FD at max. 1300kg: 1664mm, drawbar section K round 88.9x8.8mm, spacer V 415mm, perm. nose load 100kg, with drawbar eye DIN 40.0-01, for wheel brake S 1704-7 and S 2005-7.
Price 2.149,90 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZKV 13.1 B with overrun device AK 1308 height-adjustable, with drawbar section 650 to 1300kg, 47.24.473.117
BPW (AL-KO) Drawbar installation ZKV 13.1 B with overrun device AK 1308 height-adjustable, with drawbar section 650 to 1300kg, 47.24.473.117
drawbar length L 1700mm, FD at max. 1300kg: 2223mm, drawbar section K round 88.9x8.8mm, spacer V 415mm, perm. nose load 100kg, with drawbar eye DIN 40.0-01, for wheel brake S 1704-7 and S 2005-7.
Price 2.020,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZKV 20.1 B with overrun device AK 2008 height-adjustable, with drawbar section cranked 1300 to 2000kg, 47.36.471.023
BPW (AL-KO) Drawbar installation ZKV 20.1 B with overrun device AK 2008 height-adjustable, with drawbar section cranked 1300 to 2000kg, 47.36.471.023
drawbar length L 2800mm, FD at max. 2000kg: 1526mm, drawbar section K round 101.6x10mm, spacer V 415mm, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 2.794,70 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 2.0-3 with overrun device ZAAQ2.0-3 / ZDG8-3 drawbar section cranked 1250 to 2000kg, 48.36.381.087
BPW (AL-KO) Drawbar installation ZAAR 2.0-3 with overrun device ZAAQ2.0-3 / ZDG8-3 drawbar section cranked 1250 to 2000kg, 48.36.381.087
drawbar length L 2300mm, FD at max. 2000kg: 1360mm, drawbar section K square 80x5.0mm, measure HA 55mm, thread G M10, perm. nose load 150kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 973,20 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 1.6-3 with overrun device ZAAQ1.6-3 / ZDG7-3 drawbar section cranked 800 to 1600kg, 4021607
BPW (AL-KO) Drawbar installation ZAAR 1.6-3 with overrun device ZAAQ1.6-3 / ZDG7-3 drawbar section cranked 800 to 1600kg, 4021607
drawbar length L 3500mm, FD at max. 1600kg: 1200mm, drawbar section K square 70x5.0mm, measure HA 50mm, thread G M10, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 1.046,90 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAR 1.35-1 A with overrun device PAV/SR 1.3 X drawbar section straight 700 to 1350kg, 48.25.181.040
BPW (AL-KO) Drawbar installation ZAR 1.35-1 A with overrun device PAV/SR 1.3 X drawbar section straight 700 to 1350kg, 48.25.181.040
drawbar length L 2100mm, FD at max. 1350kg: 1065mm, drawbar section K round 70x4mm, measure HA 50mm, thread G M10, perm. nose load 100kg, with coupling head EM 150 R-B, for wheel brake S 1704-7 and S 2005-7.
Price 600,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAA 2.0-1.1 with overrun device AK 2008 and removable drawbar section from 1300 to 2000kg, 47.36.181.001
BPW (AL-KO) Drawbar installation ZAA 2.0-1.1 with overrun device AK 2008 and removable drawbar section from 1300 to 2000kg, 47.36.181.001
drawbar length L 1500mm, length A 1100mm, drawbar section K 88.9x8.8mm, thread G M10, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 2005-7 and S 2504-7.
Price 1.303,30 EUR Incl. tax Excl. Shipping costs
Overrun device square type ZAAQ 2.0-3, 1250 to 2000kg, 48.36.981.000
BPW (AL-KO) Overrun device square type ZAAQ 2.0-3, 1250 to 2000kg, 48.36.981.000
connection dimension B 80mm, nose load 100kg, combined with BPW wheel brake S1704-7, S2005-7 and S2504-7 RASK, with coupling head EM 220 R-B.
Price 458,10 EUR Incl. tax Excl. Shipping costs
Vertical bolts
BPW (AL-KO) Vertical bolts
mounting part kit, screw connection kit for ZEA drawbars.
Price 51,10 EUR Incl. tax Excl. Shipping costs
Towbar connection (pair) ZEA 2.0-1.1 to 2000kg, 05.447.26.23.1
BPW (AL-KO) Towbar connection (pair) ZEA 2.0-1.1 to 2000kg, 05.447.26.23.1
total length GL 1800mm, nose load 150kg.
Price 242,60 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 5.0-1.1 height-adjustable with drawbar section up to 5000kg, 47.62.403.002
BPW (AL-KO) Towbar connection ZOV 5.0-1.1 height-adjustable with drawbar section up to 5000kg, 47.62.403.002
drawbar length L 2500mm, drawbar section K 127mm, with DIN drawbar eye dimension A 716mm, height B 0-413mm, intermediate piece V 550mm, perm. nose load 400kg.
Price 2.052,60 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.009
BPW (AL-KO) Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.009
drawbar length L 1590mm, drawbar section K 108/90mm, with DIN drawbar eye dimension A 601mm, height B 0-338mm, intermediate piece V 450mm, perm. nose load 150kg.
Price 1.335,90 EUR Incl. tax Excl. Shipping costs
Drawbar ZOR 0,75-1 A round tube cranked up to 750kg, 48.14.301.013
BPW (AL-KO) Drawbar ZOR 0,75-1 A round tube cranked up to 750kg, 48.14.301.013
total length L 2600mm, drawbar section K dimension K 70x4mm, perm. nose load 75kg, coupling head EM 80 R-GK, including skid bracket, clamping bracket and plug holder.
Price 300,90 EUR Incl. tax Excl. Shipping costs
Drawbar ZOR 0,75-1 A round tube straight up to 750kg, 48.14.101.010
BPW (AL-KO) Drawbar ZOR 0,75-1 A round tube straight up to 750kg, 48.14.101.010
total length L 2000mm, drawbar section K dimension K 70x4mm, perm. nose load 75kg, coupling head EM 80 R-GK, including skid bracket, clamping bracket and plug holder.
Price 253,90 EUR Incl. tax Excl. Shipping costs
Brake shoes, wheel brake R 234-76, brake size 230x40mm
BPW (AL-KO) Brake shoes, wheel brake R 234-76, brake size 230x40mm
consisting of brake shoes, tension springs, hold down spring, for one axle (2 wheel brakes left + right).
Price 118,80 EUR Incl. tax Excl. Shipping costs
Braked axle 1350kg / 1400kg axle type SCB 1355, 46.25.379.942, 4013357
BPW (AL-KO) Braked axle 1350kg / 1400kg axle type SCB 1355, 46.25.379.942, 4013357
BC: dimension AM 1495mm, OHF: dimension FL 2040mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm.
Price 1.395,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1800kg axle type SCB 1605, 46.29.368.914
BPW (AL-KO) Braked axle 1800kg axle type SCB 1605, 46.29.368.914
BC: dimension AM 1420mm, OHF: dimension FL 2070mm, wheel connection 112x5, wheel brake type S 2504-7 RASK, offset (ET) 30mm, swing arm position 15°, axle profile 95mm, ball-head wheel bolts M12x1.5.
Price 1.550,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1050kg / 1400kg axle type SCB 1054, 46.21.379.924
BPW (AL-KO) Braked axle 1050kg / 1400kg axle type SCB 1054, 46.21.379.924
BC: dimension AM 1495mm, OHF: dimension FL 1940mm, wheel connection 100x4, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 25°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 1.300,00 EUR Incl. tax Excl. Shipping costs
Axle without brakes 2100kg FIAT DUCATO axle type DB 2100, 37.92.000.010
BPW (AL-KO) Axle without brakes 2100kg FIAT DUCATO axle type DB 2100, 37.92.000.010
BC: dimension AM 1480mm, OHF: dimension FL 1804mm, connection 82x82mm, WITHOUT wheel brake, swing arm position 5°, axle profile 92mm.
Price 4.200,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1350kg axle type CB 1354, 46.24.379.421
BPW (AL-KO) Braked axle SWING 1350kg axle type CB 1354, 46.24.379.421
BC: dimension AM 750mm, OHF: dimension FL 1190mm, wheel connection 100x4, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm.
Price 580,00 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 1.0-3, 540 to 1000kg, 48.20.581.012
BPW (AL-KO) Overrun device V type ZAF 1.0-3, 540 to 1000kg, 48.20.581.012
connection 166mm, nose load 75kg, drawbar installation version top, combined with BPW wheel brake S1704-7 and S2005-7 RASK, with coupling head WS 3000-D.
Price 450,00 EUR Incl. tax Excl. Shipping costs
Towbar connection (pair) ZEA 2.8-3 C to 2800kg, 05.447.27.04.1
BPW (AL-KO) Towbar connection (pair) ZEA 2.8-3 C to 2800kg, 05.447.27.04.1
total length GL 1844mm, nose load 150kg.
Price 365,00 EUR Incl. tax Excl. Shipping costs
