RUNNING WELL FOR YOU. BPW BERGISCHE AXLES

AL-KO Technology Paderborn GmbH specialises in the development and manufacture of complete running gear technology for car trailers and self-propelled vehicles. The location has developed from a labour-intensive wagon maker into an innovative, modern industrial company. Since 2017 the former BPW Fahrzeugtechnik has been part of the global technology company DexKo Global Inc., a worldwide market leader for trailer axles and chassis components in the lightweight segment. Read more...

Underpinning Your Progress.
The range of running gear for towable machinery, car and light truck trailers, caravans and cab & engine vehicles.



Braked axle 1050kg SWING axle type CB 1055, 46.21.379.633
BPW (AL-KO) Braked axle 1050kg SWING axle type CB 1055, 46.21.379.633
BC: dimension AM 1650mm, OHF: dimension FL 2100mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 590,80 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 850kg SWING axle type CB 855, 46.16.382.078
BPW (AL-KO) Braked tandem front axle 850kg SWING axle type CB 855, 46.16.382.078
BC: dimension AM 1400mm, OHF: dimension FL 1830mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 501,90 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1500kg axle type CB 1505, 46.27.379.418, HUMBAUR
BPW (AL-KO) Braked axle SWING 1500kg axle type CB 1505, 46.27.379.418, HUMBAUR
BC: dimension AM 1100mm, OHF: dimension FL 1550mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 850,00 EUR Incl. tax Excl. Shipping costs
Unbraked axle 750kg SWING axle type CB 755, 46.14.000.229
BPW (AL-KO) Unbraked axle 750kg SWING axle type CB 755, 46.14.000.229
BC: dimension AM 1300mm, OHF: dimension FL 1690mm, wheel connection 100x4, offset (ET) 30mm, ball-head wheel bolts M12x1.5.
Price 472,90 EUR Incl. tax Excl. Shipping costs
Unbraked axle 750kg SWING axle type CB 755, 46.14.000.220
BPW (AL-KO) Unbraked axle 750kg SWING axle type CB 755, 46.14.000.220
BC: dimension AM 850mm, OHF: dimension FL 1240mm, wheel connection 100x4, offset (ET) 30mm, ball-head wheel bolts M12x1.5.
Price 446,90 EUR Incl. tax Excl. Shipping costs
Unbraked axle 750kg SWING axle type CB 754, 46.14.000.204
BPW (AL-KO) Unbraked axle 750kg SWING axle type CB 754, 46.14.000.204
BC: dimension AM 1050mm, OHF: dimension FL 1440mm, wheel connection 100x4, offset (ET) 30mm, taper-head wheel bolts M12x1.5.
Price 455,90 EUR Incl. tax Excl. Shipping costs
Coupling head up to 1200kg
BPW (AL-KO) Coupling head up to 1200kg
suitable for overrun devices ZOV 1.2-1.1 B.
Price 323,40 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAV 2.0-5 with overrun device AE 2.7-1 C height-adjustable, with drawbar section 1500 to 2000kg, 47.36.470.081
BPW (AL-KO) Drawbar installation ZAV 2.0-5 with overrun device AE 2.7-1 C height-adjustable, with drawbar section 1500 to 2000kg, 47.36.470.081
drawbar length L 1900mm, measure B 0-520mm, FD at max. 2000kg: 3000mm, drawbar section K square 120mm, spacer V 600mm, perm. nose load 150kg, without hitch components, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 2.000,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAV 2.0-5 with overrun device AE 2.7-1 C height-adjustable, with drawbar section 1500 to 2000kg, 47.36.470.077
BPW (AL-KO) Drawbar installation ZAV 2.0-5 with overrun device AE 2.7-1 C height-adjustable, with drawbar section 1500 to 2000kg, 47.36.470.077
drawbar length L 1900mm, measure B 0-693mm, FD at max. 2000kg: 3000mm, drawbar section K square 120mm, spacer V 800mm, perm. nose load 150kg, without hitch components, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 2.050,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAV 2.0-5 with overrun device AE 2.7-1 C height-adjustable, with drawbar section 1500 to 2000kg, 47.36.470.113
BPW (AL-KO) Drawbar installation ZAV 2.0-5 with overrun device AE 2.7-1 C height-adjustable, with drawbar section 1500 to 2000kg, 47.36.470.113
drawbar length L 2500mm, measure B 0-693mm, FD at max. 2000kg: 3000mm, drawbar section K square 120mm, spacer V 800mm, perm. nose load 150kg, without hitch components, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 2.150,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAV 1.6-5 with overrun device AE 2.7-1 D height-adjustable, with drawbar section 1200 to 1600kg, 47.29.470.066
BPW (AL-KO) Drawbar installation ZAV 1.6-5 with overrun device AE 2.7-1 D height-adjustable, with drawbar section 1200 to 1600kg, 47.29.470.066
drawbar length L 2300mm, measure B 0-693mm, FD at max. 1600kg: 3000mm, drawbar section K square 120mm, spacer V 800mm, perm. nose load 150kg, without hitch components, for wheel brake S 1704-7 and S 2005-7.
Price 2.389,40 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZKV 13.1 B with overrun device AK 1308 height-adjustable, with drawbar section 650 to 1300kg, 47.24.473.116
BPW (AL-KO) Drawbar installation ZKV 13.1 B with overrun device AK 1308 height-adjustable, with drawbar section 650 to 1300kg, 47.24.473.116
drawbar length L 1500mm, FD at max. 1300kg: 2223mm, drawbar section K round 88.9x8.8mm, spacer V 415mm, perm. nose load 100kg, with drawbar eye DIN 40.0-01, for wheel brake S 1704-7 and S 2005-7.
Price 2.150,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 2.0-3 with overrun device ZAAQ2.0-3 / ZDG8-3 drawbar section cranked 1250 to 2000kg, 48.36.381.088
BPW (AL-KO) Drawbar installation ZAAR 2.0-3 with overrun device ZAAQ2.0-3 / ZDG8-3 drawbar section cranked 1250 to 2000kg, 48.36.381.088
drawbar length L 2500mm, FD at max. 2000kg: 1360mm, drawbar section K square 80x5.0mm, measure HA 55mm, thread G M10, perm. nose load 150kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 993,60 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 2.0-3 with overrun device ZAAQ2.0-3 / ZDG8-3 drawbar section cranked 1250 to 2000kg, 48.36.381.086
BPW (AL-KO) Drawbar installation ZAAR 2.0-3 with overrun device ZAAQ2.0-3 / ZDG8-3 drawbar section cranked 1250 to 2000kg, 48.36.381.086
drawbar length L 2100mm, FD at max. 2000kg: 1360mm, drawbar section K square 80x5.0mm, measure HA 55mm, thread G M10, perm. nose load 150kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 952,70 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 3.0-1 with overrun device ZAAQ3.0 / ZDG10-3 drawbar section straight 1800 to 2800kg, 48.46.181.002
BPW (AL-KO) Drawbar installation ZAAR 3.0-1 with overrun device ZAAQ3.0 / ZDG10-3 drawbar section straight 1800 to 2800kg, 48.46.181.002
drawbar length L 2300mm, FD at max. 2800kg: 1780mm, drawbar section K square 100x6.3mm, measure HA 65mm, thread G M10, perm. nose load 100kg, with coupling head EM 300 R-B-K1212, for wheel brake S 2005-7, S 2504-7 and S 3006-7.
Price 776,90 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 3.0-1 with overrun device ZAAQ3.0 / ZDG10-3 drawbar section straight 1800 to 2800kg, 48.46.181.001
BPW (AL-KO) Drawbar installation ZAAR 3.0-1 with overrun device ZAAQ3.0 / ZDG10-3 drawbar section straight 1800 to 2800kg, 48.46.181.001
drawbar length L 2100mm, FD at max. 2800kg: 1780mm, drawbar section K square 100x6.3mm, measure HA 65mm, thread G M10, perm. nose load 100kg, with coupling head EM 300 R-B-K1212, for wheel brake S 2005-7, S 2504-7 and S 3006-7.
Price 862,30 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 1.6-1 with overrun device ZAAQ1.6 / ZDG7-3 drawbar section straight 800 to 1600kg, 48.29.181.057
BPW (AL-KO) Drawbar installation ZAAR 1.6-1 with overrun device ZAAQ1.6 / ZDG7-3 drawbar section straight 800 to 1600kg, 48.29.181.057
drawbar length L 3000mm, FD at max. 1600kg: 1200mm, drawbar section K square 70x5.0mm, measure HA 50mm, thread G M10, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 697,00 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 3.0-3, 1800 to 2800kg, 48.44.581.201
BPW (AL-KO) Overrun device V type ZAF 3.0-3, 1800 to 2800kg, 48.44.581.201
connection 166mm, nose load 150kg, drawbar installation version top + bottom, combined with BPW wheel brake S2005-7, S2504-7 and S3006-7 RASK, with coupling head EM 300 R-B.
Price 499,00 EUR Incl. tax Excl. Shipping costs
Towbar connection (pair) ZEA 3.5-1.1 to 3500kg, 05.447.26.21.1
BPW (AL-KO) Towbar connection (pair) ZEA 3.5-1.1 to 3500kg, 05.447.26.21.1
total length GL 2150mm, nose load 150kg.
Price 346,30 EUR Incl. tax Excl. Shipping costs
Cup
BPW (AL-KO) Cup
can be used with wheel brake S 3006-5 SK, S 3006-5 RASK and S 3006-6 RASK.
Price 6,80 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 1.6-3, 750 to 1500kg, 48.27.581.007
BPW (AL-KO) Overrun device V type ZAF 1.6-3, 750 to 1500kg, 48.27.581.007
connection 166mm, nose load 100kg, drawbar installation version top + bottom, combined with BPW wheel brake S1704-7, S2005-7 and S2504-7 RASK, with coupling head WW150R-B.
Price 329,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1350kg / 1400kg axle type SCB 1355, 46.25.379.922, 4020120
BPW (AL-KO) Braked axle 1350kg / 1400kg axle type SCB 1355, 46.25.379.922, 4020120
BC: dimension AM 1420mm, OHF: dimension FL 2070mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 25°, axle profile 95mm, ball-head wheel bolts M12x1.5.
Price 1.450,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1700kg axle type SCB 1605, (new CB 1605), 46.29.368.080, 4013656
BPW (AL-KO) Braked axle 1700kg axle type SCB 1605, (new CB 1605), 46.29.368.080, 4013656
BC: dimension AM 1496mm, OHF: dimension FL 2080mm, wheel connection 112x5, wheel brake type S 2504-7 RASK, offset (ET) 30mm, swing arm position 25°, axle profile 95mm, ball-head wheel bolts M12x1.5.
Price 1.695,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1500kg axle type CB 1505, 46.27.379.750
BPW (AL-KO) Braked axle SWING 1500kg axle type CB 1505, 46.27.379.750
BC: dimension AM 1710mm, OHF: dimension FL 2080mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 25°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 1.295,00 EUR Incl. tax Excl. Shipping costs
