Braked tandem front axle 1050kg BASIC axle type CB1050
AL-KO Braked tandem front axle 1050kg BASIC axle type CB1050
BC: dimension A 1700mm, OHF: dimension B 2150mm, wheel connection 112x5, wheel brake type 2051, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 603,00 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg BASIC axle type CB1050
AL-KO Braked tandem front axle 1050kg BASIC axle type CB1050
BC: dimension A 1600mm, OHF: dimension B 2050mm, wheel connection 112x5, wheel brake type 2051, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 597,00 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg BASIC axle type CB1050
AL-KO Braked tandem front axle 1050kg BASIC axle type CB1050
BC: dimension A 1400mm, OHF: dimension B 1850mm, wheel connection 112x5, wheel brake type 2051, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 586,00 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg BASIC axle type CB1050
AL-KO Braked tandem front axle 1050kg BASIC axle type CB1050
BC: dimension A 1200mm, OHF: dimension B 1650mm, wheel connection 112x5, wheel brake type 2051, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 575,00 EUR Incl. tax Excl. Shipping costs
Overrun device height-adjustable 350 VB BASIC with drawbar section 2500 to 3500kg
AL-KO Overrun device height-adjustable 350 VB BASIC with drawbar section 2500 to 3500kg
total length K (at 0°) 3250mm, drawbar length E 1950mm, drawbar section 120x160x6mm, intermediate piece 400mm, perm. nose load 150kg, without hitch components, for wheel brake 2051.
Price 1.937,90 EUR Incl. tax Excl. Shipping costs
Overrun device height-adjustable 350 VB BASIC with drawbar section 2500 to 3500kg
AL-KO Overrun device height-adjustable 350 VB BASIC with drawbar section 2500 to 3500kg
total length K (at 0°) 3010mm, drawbar length E 1710mm, drawbar section 120x160x6mm, intermediate piece 400mm, perm. nose load 150kg, without hitch components, for wheel brake 2051.
Price 1.906,90 EUR Incl. tax Excl. Shipping costs
Ball pin type CHP
AL-KO Ball pin type CHP
hole pattern 90x50mm, 4 holes Ø17mm, tensile load max. 3500kg, nose load 120kg, type approval no. E2 55R-0112212, D/Dc value 17.2 kN, for drawbar eyes 43x68mm or 42x76mm, Achs Ø32mm, dimension A 175mm, dimension B 222mm, dimension C 105mm.
Price 383,00 EUR Incl. tax Excl. Shipping costs
Drawbar section type 751 VB to 6500kg
AL-KO Drawbar section type 751 VB to 6500kg
drawbar length E 2875mm, drawbar section 120x220x10mm, surface treatment: black primed.
Price 1.526,00 EUR Incl. tax Excl. Shipping costs
Drawbar connection profile
AL-KO Drawbar connection profile
single axle 1200-5, 1600-3, B 1200 and B 1600, axle profile 97mm, drawbar tube round 70mm and 88.9mm, drawbar tube square 70x70mm and 100x100mm.
Price 85,90 EUR Incl. tax Excl. Shipping costs
Wheel brake 2361 (pair), pneumatic brakes
AL-KO Wheel brake 2361 (pair), pneumatic brakes
wheel load per hub 1800kg, wheel connection (G) 112x5, thread M12x1.5, offset (ET) 27-33mm, screwplate.
Price 1.616,00 EUR Incl. tax Excl. Shipping costs
Wheel brake 1637 AR (pair)
AL-KO Wheel brake 1637 AR (pair)
wheel load per hub 900kg, wheel connection (G) 112x5, thread M12x1.5, offset (ET) 27-33mm, axle stub 51mm.
Price 467,00 EUR Incl. tax Excl. Shipping costs
Axle with pneumatic brakes 3000kg axle type BL 3000 with shock absorber bracket
AL-KO Axle with pneumatic brakes 3000kg axle type BL 3000 with shock absorber bracket
BC: dimension A 1330mm, OHF: dimension C 1800mm, wheel connection 205x6, wheel brake type 3062 AR, offset (ET) 0mm, swing arm position 25°, wheel nut ball M18x1.5.
Price 3.406,00 EUR Incl. tax Excl. Shipping costs
Axle with pneumatic brakes 3000kg axle type BL 3000 with top hat profilee 130mm and shock absorber bracket
AL-KO Axle with pneumatic brakes 3000kg axle type BL 3000 with top hat profilee 130mm and shock absorber bracket
BC: dimension A 1530mm, OHF: dimension C 2000mm, wheel connection 205x6, wheel brake type 3062 AR, offset (ET) 0mm, swing arm position 25°, axle profile 120mm, wheel nut ball M18x1.5.
Price 3.517,00 EUR Incl. tax Excl. Shipping costs
Axle with pneumatic brakes tandem 3500kg axle type BL 1800 with top hat profilee 130mm and shock absorber bracket
AL-KO Axle with pneumatic brakes tandem 3500kg axle type BL 1800 with top hat profilee 130mm and shock absorber bracket
BC: dimension A 1650mm, OHF: dimension C 2150mm, wheel connection 112x5, wheel brake type 2361 AR, offset (ET) 30mm, swing arm position 25°, ball-head wheel bolts M12x1.5.
Price 4.629,00 EUR Incl. tax Excl. Shipping costs
Brake away cable with hook
AL-KO Brake away cable with hook
length 950mm, for overrun device square (tubular) and overrun device V.
Price 6,90 EUR Incl. tax Excl. Shipping costs
Bowden cable 217738 for overrun device with thread
AL-KO Bowden cable 217738 for overrun device with thread
sheath length (A) 550mm, cable length (B) 840mm, cable thickness (C) 5mm, thread (D/E) M10 right / M10 left, suitable for types 1.3 VB without automatic reverse, 131 R and 161 R.
Price 71,90 EUR Incl. tax Excl. Shipping costs
Bowden cable 381594 for overrun device with thread and eyelet
AL-KO Bowden cable 381594 for overrun device with thread and eyelet
sheath length (A) 870mm, cable length (B) 1100mm, cable thickness (C) 6mm, thread (D) M12, suitable for types FA 0.9, FA 1.4, FA 1.5, FA 2.5 and FA 3.
Price 126,00 EUR Incl. tax Excl. Shipping costs
Lowering axles down to 140mm, axle type BRA 1600-3, tandem 3000kg
AL-KO Lowering axles down to 140mm, axle type BRA 1600-3, tandem 3000kg
BC: dimension A 1600mm, OHF: dimension C 2090mm, wheel connection 112x5, wheel brake type 2051 Ab, offset (ET) 27-35mm, ball-head wheel bolts M12x1.5, hydraulic cylinder, cylinder spacing: dimension S 1340mm.
Price 4.166,00 EUR Incl. tax Excl. Shipping costs
Lowering axles down to 140mm, axle type BRA 1600-3, tandem 3000kg
AL-KO Lowering axles down to 140mm, axle type BRA 1600-3, tandem 3000kg
BC: dimension A 1500mm, OHF: dimension C 1990mm, wheel connection 112x5, wheel brake type 2051 Ab, offset (ET) 27-35mm, ball-head wheel bolts M12x1.5, hydraulic cylinder, cylinder spacing: dimension S 1240mm.
Price 4.155,00 EUR Incl. tax Excl. Shipping costs
Lowering axle down to 210mm, axle type BRA 1800-9, single axle 1800kg
AL-KO Lowering axle down to 210mm, axle type BRA 1800-9, single axle 1800kg
BC: dimension A 1200mm, OHF: dimension C 1750mm, wheel connection 112x5, wheel brake type 2361, offset (ET) 27-35mm, ball-head wheel bolts M12x1.5, hydraulic cylinder, cylinder spacing: dimension S 940mm.
Price 3.181,00 EUR Incl. tax Excl. Shipping costs
Brake back plate right 2051
AL-KO Brake back plate right 2051
for wheel brake AL-KO 2051, brake size 200x50mm, surface treatment galvanised.
Price 89,90 EUR Incl. tax Excl. Shipping costs
Square overrun device type 161 S - ZE 252R with removable drawbar section from 950 to 1600kg
AL-KO Square overrun device type 161 S - ZE 252R with removable drawbar section from 950 to 1600kg
total length A 2635mm, drawbar length C 1375mm, drawbar section 88.9x7.1mm, perm. nose load 100kg, with coupling head AK 161, for wheel brake 2361.
Price 1.488,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 161 S - ZE 252R with removable drawbar section from 950 to 1600kg
AL-KO Square overrun device type 161 S - ZE 252R with removable drawbar section from 950 to 1600kg
total length A 2315mm, drawbar length C 1055mm, drawbar section 88.9x7.1mm, perm. nose load 100kg, with coupling head AK 161, for wheel brake 2361.
Price 1.435,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 161 S - ZE 252R with removable drawbar section from 950 to 1600kg
AL-KO Square overrun device type 161 S - ZE 252R with removable drawbar section from 950 to 1600kg
total length A 2795mm, drawbar length C 1535mm, drawbar section 88.9x7.1mm, perm. nose load 100kg, with coupling head AK 161, for wheel brake 1637 / 2051.
Price 1.506,00 EUR Incl. tax Excl. Shipping costs
