BC: dimension A 1504/1570mm, OHF: dimension C 2025mm, wheel connection 139.7x4, wheel brake type 2051, offset (ET) 25.4mm, swing arm position 25°, axle profile 97mm.
BC: dimension A 1220mm, OHF: dimension C 1670mm, wheel connection 100x4, wheel brake type 2051 A, offset (ET) 27-33mm, swing arm position 25°, axle profile 80mm, taper-head wheel bolts M12x1.5.
BC: dimension A 1300mm, OHF: dimension C 1680mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 30-33mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Ramp made from aluminium type 400/2000/200, straight, length L 2000, width B 200, height S 50, loading height min.-max H 400-600mm, load capacity 385-839kg.
