Drawbar eye DIN ø40mm
AL-KO Drawbar eye DIN ø40mm
perm. gross weight 6500kg, material: cast iron, hot-dip galvanised.
Price 888,00 EUR Incl. tax Excl. Shipping costs
Brake shoes, wheel brake SB 135.30 brake size 135x30mm
AL-KO Brake shoes, wheel brake SB 135.30 brake size 135x30mm
consisting of brake shoes, for one axle (2 wheel brakes left + right).
Price 130,00 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1350kg BASIC axle type CB1350 with AAA (automatic adjustment of the brake pads)
AL-KO Braked tandem front axle 1350kg BASIC axle type CB1350 with AAA (automatic adjustment of the brake pads)
BC: dimension A 1300mm, OHF: dimension B 1750mm, wheel connection 112x5, wheel brake type 2051 with AAA, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 702,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1350kg EURO COMPACT axle type B 1200-6 - HUMBAUR
AL-KO Braked axle 1350kg EURO COMPACT axle type B 1200-6 - HUMBAUR
BC: dimension A 700mm, OHF: dimension C 1100mm, wheel connection 112x5, wheel brake type 2051 vers. Ad, offset (ET) 30-33mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 799,00 EUR Incl. tax Excl. Shipping costs
Braked axle 750kg BASIC axle type B 700-5
AL-KO Braked axle 750kg BASIC axle type B 700-5
BC: dimension A 1190mm, OHF: dimension C 1630mm, wheel connection 98x4, wheel brake type 1637, offset (ET) 27-45mm, swing arm position 30°, axle profile 71mm, taper-head wheel bolts M12x1.5.
Price 725,00 EUR Incl. tax Excl. Shipping costs
Spare wheel carrier type EH1, implementation C
AL-KO Spare wheel carrier type EH1, implementation C
frame gap dimension A 1450-1850mm, surface treatment galvanised.
Price 254,00 EUR Incl. tax Excl. Shipping costs
Storage box for car trailer, cover hinges on the side
AL-KO Storage box for car trailer, cover hinges on the side
max. load 20kg suspended, external dimensions LxWxH 515x226x272mm, height inc. turning handle 305mm, internal dimensions LxWxH 445x145x220mm.
Price 171,00 EUR Incl. tax Excl. Shipping costs
Soft.Ball, red. without packaging
AL-KO Soft.Ball, red. without packaging
1 unit, for towing hitch with 50mm ball, colour red similar to RAL 3000.
Price 10,90 EUR Incl. tax Excl. Shipping costs
Drawbar connection profile
AL-KO Drawbar connection profile
single axle 1200-5, 1600-3, B 1200 and B 1600, axle profile 97mm, drawbar tube round 70mm and 88.9mm, drawbar tube square 70x70mm and 100x100mm.
Price 85,90 EUR Incl. tax Excl. Shipping costs
Braked axle EURO PLUS tandem 3500kg with shock absorber bracket
AL-KO Braked axle EURO PLUS tandem 3500kg with shock absorber bracket
BC: dimension A 1830mm, OHF: dimension C 2240mm, wheel connection 112x5, wheel brake type 2361, ball-head wheel bolts M12x1.5.
Price 2.500,00 EUR Incl. tax Excl. Shipping costs
Braked axle EURO PLUS tandem 3500kg with tandem adapter bracket from top/bottom
AL-KO Braked axle EURO PLUS tandem 3500kg with tandem adapter bracket from top/bottom
BC: dimension A 1100mm, OHF: dimension C 1855mm, wheel connection 112x5, wheel brake type 2361, ball-head wheel bolts M12x1.5.
Price 1.950,00 EUR Incl. tax Excl. Shipping costs
Braked axle COMPACT tandem 2700kg with top hat profile 130mm
AL-KO Braked axle COMPACT tandem 2700kg with top hat profile 130mm
BC: dimension A 1300mm, OHF: dimension C 1750mm, wheel connection 112x5, wheel brake type 2051, ball-head wheel bolts M12x1.5.
Price 1.394,00 EUR Incl. tax Excl. Shipping costs
Bowden cable 350503 for overrun device with thread
AL-KO Bowden cable 350503 for overrun device with thread
sheath length (A) 700mm, cable length (B) 1000mm, cable thickness (C) 8mm, thread (D/E) M12 right / M12 right, suitable for types 2.0 VB with automatic reverse.
Price 149,90 EUR Incl. tax Excl. Shipping costs
Bowden cable 2075750001 for overrun device with thread
AL-KO Bowden cable 2075750001 for overrun device with thread
sheath length (A) 400mm, cable length (B) 690mm, cable thickness (C) 5mm, thread (D/E) M10 right / M10 left, suitable for types 1.3 VB without automatic reverse.
Price 139,90 EUR Incl. tax Excl. Shipping costs
Bowden cable 217746 for overrun device with thread and eyelet
AL-KO Bowden cable 217746 for overrun device with thread and eyelet
sheath length (A) 700mm, cable length (B) 910mm, cable thickness (C) 6mm, thread (D) M12, suitable for types 2.0 VB with automatic reverse.
Price 79,90 EUR Incl. tax Excl. Shipping costs
Lowering half axle down to 270mm, axle type ASB1800, single axle 1800kg, tandem 3500kg
AL-KO Lowering half axle down to 270mm, axle type ASB1800, single axle 1800kg, tandem 3500kg
BC: dimension A 449mm, OHF: dimension C 785mm, wheel connection 112x5, wheel brake 2361, offset (ET) 30mm, ball-head wheel bolts M12x1.5, see technical drawing.
Price 4.350,00 EUR Incl. tax Excl. Shipping costs
Overrun device V type AE3500, 2000 to 3500kg, with lowering handbrake lever
AL-KO Overrun device V type AE3500, 2000 to 3500kg, with lowering handbrake lever
connection 166/207mm, nose load 350kg, drawbar installation version top + bottom, can be combined with AL-KO wheel brake 3062 / 3081, with coupling head AK 351.
Price 963,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 251 S - ZE 252R with removable drawbar section from 1500 to 2600kg
AL-KO Square overrun device type 251 S - ZE 252R with removable drawbar section from 1500 to 2600kg
total length A 2165mm, drawbar length C 905mm, drawbar section 88.9x5.6mm, perm. nose load 100kg, with drawbar eye D40/F, for wheel brake 2361.
Price 1.555,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 251 S - ZE 252R with removable drawbar section from 1500 to 2600kg
AL-KO Square overrun device type 251 S - ZE 252R with removable drawbar section from 1500 to 2600kg
total length A 2165mm, drawbar length C 905mm, drawbar section 88.9x5.6mm, perm. nose load 100kg, with coupling head AK 270, for wheel brake 2361.
Price 1.543,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
AL-KO Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
total length A 3930mm, drawbar length C 2377mm, drawbar section 120x120x8mm, perm. nose load 150kg, without hitch component, for wheel brake 2051.
Price 3.738,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
AL-KO Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
total length A 3610mm, drawbar length C 2057mm, drawbar section 120x120x8mm, perm. nose load 150kg, without hitch component, for wheel brake 2051.
Price 3.676,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 251 S - K26-S with sideways swivelling drawbar section from 1500 to 2600kg
AL-KO Square overrun device type 251 S - K26-S with sideways swivelling drawbar section from 1500 to 2600kg
total length A 4010mm, drawbar length C 2750mm, drawbar section 100x100x6mm, perm. nose load 100kg, with coupling head AK 270, for wheel brake 2361.
Price 1.993,00 EUR Incl. tax Excl. Shipping costs
Crank
AL-KO Crank
Price 67,90 EUR Incl. tax Excl. Shipping costs
Braked half axles 2500kg axle type B 2500-8 (pair)
AL-KO Braked half axles 2500kg axle type B 2500-8 (pair)
BC: dimension A 410mm, OHF: dimension C 668mm, wheel connection 205x6, wheel brake type 3062, offset (ET) 0mm, swing arm position 5°, axle profile 120mm, wheel nuts M18x1.5 ball.
Price 2.652,00 EUR Incl. tax Excl. Shipping costs
Page 29 of 473
