AL-KO

Home / Brands / AL-KO

JUST ORIGINAL PARTS

LIFE-TIME SUPPORT

SALE

POSITIVE REVIEWS

Braked axle 1050kg BASIC axle type CB1050
AL-KO Braked axle 1050kg BASIC axle type CB1050
BC: dimension A 1100mm, OHF: dimension B 1550mm, wheel connection 112x5, wheel brake type 2051, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 570,00 EUR Incl. tax Excl. Shipping costs
Braked tandem axle unit 2000kg EURO COMPACT axle type 2xB 850-10
AL-KO Braked tandem axle unit 2000kg EURO COMPACT axle type 2xB 850-10
BC: dimension A 1600mm, OHF: dimension C 2030mm, wheel connection 100x4, wheel brake type 2051A, offset (ET) 27-33mm, swing arm position 25°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 1.495,00 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1000kg BASIC axle type B 850-10
AL-KO Braked tandem front axle 1000kg BASIC axle type B 850-10
BC: dimension A 1625mm, OHF: dimension C 2075mm, wheel connection 98x4, wheel brake type 2051, offset (ET) 27-33mm, swing arm position 25°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 506,90 EUR Incl. tax Excl. Shipping costs
Spread hinge lock
AL-KO Spread hinge lock
dimension A 57mm, can be used with wheel brake SB160, SR160, 1625, 1640, 1635, 1636 and 1637.
Price 30,90 EUR Incl. tax Excl. Shipping costs
Overrun device height-adjustable 350 VB BASIC with drawbar section 2500 to 3500kg
AL-KO Overrun device height-adjustable 350 VB BASIC with drawbar section 2500 to 3500kg
total length K (at 0°) 3090mm, drawbar length E 1790mm, drawbar section 120x160x6mm, intermediate piece 400mm, perm. nose load 150kg, without hitch components, for wheel brake 2051.
Price 1.906,90 EUR Incl. tax Excl. Shipping costs
Overrun device height-adjustable 350 VB BASIC with drawbar section 2500 to 3500kg
AL-KO Overrun device height-adjustable 350 VB BASIC with drawbar section 2500 to 3500kg
total length K (at 0°) 2930mm, drawbar length E 1630mm, drawbar section 120x160x6mm, intermediate piece 400mm, perm. nose load 150kg, without hitch components, for wheel brake 2051.
Price 1.890,90 EUR Incl. tax Excl. Shipping costs
Overrun device height-adjustable 350 VB BASIC with drawbar section 2500 to 3500kg
AL-KO Overrun device height-adjustable 350 VB BASIC with drawbar section 2500 to 3500kg
total length K (at 0°) 2610mm, drawbar length E 1310mm, drawbar section 120x160x6mm, intermediate piece 400mm, perm. nose load 150kg, without hitch components, for wheel brake 2051.
Price 1.843,90 EUR Incl. tax Excl. Shipping costs
Holding link
AL-KO Holding link
for screwing on.
Price 12,90 EUR Incl. tax Excl. Shipping costs
Ball pin type CHG35
AL-KO Ball pin type CHG35
hole pattern 120x55mm, 4 holes Ø15mm, tensile load max. 3500kg, nose load 150kg, type approval no. E2 55R-0112213, D/Dc value 27.5 kN, for drawbar eyes 42x68mm or 42x76mm, Achs Ø32mm, dimension A 175mm, dimension B 222mm, dimension C 105mm.
Price 465,00 EUR Incl. tax Excl. Shipping costs
Pintle type 32C
AL-KO Pintle type 32C
hole pattern 85x44mm, 4 holes Ø13mm, tensile load max. 3500kg, nose load 340kg, type approval no. E2 55R-0112209, D/Dc value 31 kN, for drawbar eyes 42x68mm or 42x76mm, dimension A 127mm, dimension B 140mm, dimension B' 185mm, dimension C 155mm.
Price 243,00 EUR Incl. tax Excl. Shipping costs
Pintle "Combi" type 8943
AL-KO Pintle "Combi" type 8943
hole pattern 90x40mm, 4 holes Ø17mm, tensile load max. 3500kg, nose load 340kg, type approval no. E2 55R-0112211, D/Dc value 31 kN, for drawbar eyes 42x68mm or 42x76mm, dimension A 122mm, dimension B 210mm, dimension B' 245mm, dimension C 160mm.
Price 393,00 EUR Incl. tax Excl. Shipping costs
Towball Typ 167
AL-KO Towball Typ 167
hole pattern 83x56mm, 4 holes Ø11mm, nose load 200kg, D/Dc value 17.5 kN, surface treatment black primed.
Price 202,00 EUR Incl. tax Excl. Shipping costs
Compensation profilee 3062/3081
AL-KO Compensation profilee 3062/3081
can be used for AL-KO wheel brakes 3062 and 3081.
Price 16,90 EUR Incl. tax Excl. Shipping costs
Welded/bolted connection
AL-KO Welded/bolted connection
weight range single axle 750kg, axle profile 71mm, swing arm standard degrees: 30°, drawbar section round 70mm and 88.9mm, rectangular width 70mm and 80mm, dimension A 175mm, dimension B 190mm, dimension C 80mm, dimension D 12.5mm, dimension E 12.5mm, dim
Price 74,90 EUR Incl. tax Excl. Shipping costs
Adapter bracket increase
AL-KO Adapter bracket increase
over 1900kg, hot-dip galvanised.
Price 18,90 EUR Incl. tax Excl. Shipping costs
Drawbar connection profile
AL-KO Drawbar connection profile
single axle 850-10, B 850 and B 1000, axle profile 80mm, drawbar tube square 70x110mm, 70x140mm and 80x140mm.
Price 131,00 EUR Incl. tax Excl. Shipping costs
Wheel brake 2361 (pair)
AL-KO Wheel brake 2361 (pair)
wheel load per hub 1800kg, wheel connection (G) 165.1x5, thread M14x1.5, offset (ET) 0mm, axle stub 42mm.
Price 1.206,00 EUR Incl. tax Excl. Shipping costs
Wheel brake 1637 AR (pair)
AL-KO Wheel brake 1637 AR (pair)
wheel load per hub 900kg, wheel connection (G) 100x4, thread M12x1.5, offset (ET) 27-33mm, axle stub 46mm.
Price 467,00 EUR Incl. tax Excl. Shipping costs
Axle with pneumatic brakes tandem 6000kg axle type BL 3000 with top hat profilee 130mm and shock absorber bracket
AL-KO Axle with pneumatic brakes tandem 6000kg axle type BL 3000 with top hat profilee 130mm and shock absorber bracket
BC: dimension A 1360mm, OHF: dimension C 1900mm, wheel connection 205x6, wheel brake type 3062 AR, offset (ET) 0mm, swing arm position 25°, wheel nut ball M18x1.5.
Price 6.349,00 EUR Incl. tax Excl. Shipping costs
Axle with pneumatic brakes tandem 3500kg axle type BL 1800 with top hat profilee 130mm and shock absorber bracket
AL-KO Axle with pneumatic brakes tandem 3500kg axle type BL 1800 with top hat profilee 130mm and shock absorber bracket
BC: dimension A 1850mm, OHF: dimension C 2350mm, wheel connection 112x5, wheel brake type 2361 AR, offset (ET) 30mm, swing arm position 25°, ball-head wheel bolts M12x1.5.
Price 4.693,00 EUR Incl. tax Excl. Shipping costs
Axle with pneumatic brakes tandem 2800kg with top hat profile 130mm and shock absorber bracket
AL-KO Axle with pneumatic brakes tandem 2800kg with top hat profile 130mm and shock absorber bracket
BC: dimension A 1800mm, OHF: dimension C 2300mm, wheel connection 112x5, wheel brake type 2361 AR, offset (ET) 30mm, swing arm position 25°, ball-head wheel bolts M12x1.5.
Price 4.190,00 EUR Incl. tax Excl. Shipping costs
Axle with pneumatic brakes tridem 5400kg axle type BL 2000 with top hat profilee 130mm and shock absorber bracket
AL-KO Axle with pneumatic brakes tridem 5400kg axle type BL 2000 with top hat profilee 130mm and shock absorber bracket
BC: dimension A 1800mm, OHF: dimension C 2300mm, wheel connection 112x5, wheel brake type 2361 AR, offset (ET) 30mm, swing arm position 25°, axle profile 120mm, ball-head wheel bolts M12x1.5.
Price 11.340,00 EUR Incl. tax Excl. Shipping costs
Braked axle EURO PLUS tandem 3500kg with top hat profile 130mm, shock absorber bracket
AL-KO Braked axle EURO PLUS tandem 3500kg with top hat profile 130mm, shock absorber bracket
BC: dimension A 1850mm, OHF: dimension C 2350mm, wheel connection 112x5, wheel brake type 2361, ball-head wheel bolts M12x1.5.
Price 1.990,00 EUR Incl. tax Excl. Shipping costs
Braked axle COMPACT tandem 2600kg
AL-KO Braked axle COMPACT tandem 2600kg
BC: dimension A 1700mm, OHF: dimension C 2150mm, wheel connection 112x5, wheel brake type 2051, ball-head wheel bolts M12x1.5.
Price 1.358,00 EUR Incl. tax Excl. Shipping costs
Page 109 of 473
