Braked axle 1150kg SWING axle type CB 1154, 46.21.379.592, ATLAS COPCO Braked axle 1150kg SWING axle type CB 1154, 46.21.379.592, ATLAS COPCO Braked axle 1150kg SWING axle type CB 1154, 46.21.379.592, ATLAS COPCO Braked axle 1150kg SWING axle type CB 1154, 46.21.379.592, ATLAS COPCO
Braked axle 1150kg SWING axle type CB 1154, 46.21.379.592, ATLAS COPCO
Braked axle 1150kg SWING axle type CB 1154, 46.21.379.592, ATLAS COPCO
Braked axle 1150kg SWING axle type CB 1154, 46.21.379.592, ATLAS COPCO
Braked axle 1150kg SWING axle type CB 1154, 46.21.379.592, ATLAS COPCO

BPW Braked axle 1150kg SWING axle type CB 1154, 46.21.379.592, ATLAS COPCO

Home / Braked axle 1150kg SWING axle type CB 1154, 46.21.379.592, ATLAS COPCO

wheel connection 100x4, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5. Read more...

Wishlist: Add to comparison:
Price 2.280,00 EUR Incl. tax Excl. Shipping costs
Delivery time: approx. 1-3 working days (Mon-Fri)
- +
Add to cart

Product description

Part no. OLD 46.21.379.592
Part no. NEW 1604380300

Model Atlas Copco
Axle type CB1154
Axle load single axle 1150kg
Axle load: Tandem axel 2300kg
Wheel brake S 2005-7 RASK
Suspension Square rubber suspension
Swing arm 160mm
Wheel connection 100x4
Wheel bearing Compact bearings
Centre hole rim min. 56.5mm



Original operating instructions
Replacement part identification number (ETI) OLD XX.XX.379.XXX
Replacement part identification number (ETI) NEW 827030

SCOPE OF DELIVERY
Axle

DETAILS

  • Speed up to 140 km/h
  • Drawbar connection: Clamping shells see Accessories
  • Axle shock absorber see Accessories
  • Wheel connections: 98x4, 130x4, 120x5, 140x5 on demand
  • Special axle mounts and drawbar connections on demand
  • Also available with watertight bearings
  • Axle body fully hop-dip galvanised: Permanent surface protection
  • Independent wheel suspension: Optimum compensation of uneven road surfaces
  • Maintenance-free suspension: Lower maintenance costs
  • Sturdy axle construction: Suitable for extreme loads such as off-road or construction sites
  • Sturdy, maintenance-free spreadlever brakes with auto-reverse: Simple adjustment of the brake from outside the wheel, subsequent connection of the brake cables possible without removal of the brake drum
  • Compact bearings (standard in the automotive industry): Maintenance-free, long service life, protected against dirt and water, lubricated for life with special grease
  • Incl. shock absorber bracket
