Home / Towbar connection toothed washer type 102 VB vers. N height-adjustable with drawbar section up to 1100kg
total length K (at 0°) 2019mm, drawbar length E 1010mm, drawbar section 70x140x3mm, intermediate piece 750mm, perm. nose load 100kg, ohne Kupplungsteile. Read more...
Drawbar cpl. with drawbar section mounted (without hitch components)
INSTRUCTION BOOK
SPARE PART LIST 811674
TECHNOLOGY
Drawbar type 102 VB vers. N
Intermediate piece with drawbar section
Permitted nose load 100 kg
ECE type approval no.:
E1 55R-01 0211
SURFACE TREATMENT
Hot-dip galvanised
Hitches, eyes and small parts galvanised (not included in scope of delivery)
Here, you can find the catalogue page as a convenient PDF download.
You can also enter the part no. from the catalogue as a search term in our online store.
