BC: dimension A 1596mm, OHF: dimension C 1970mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm.
BC: dimension A 1250mm, OHF: dimension C 1720mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm.
BC: dimension A 930mm, OHF: dimension C 1330mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm.
BC: dimension A 1300mm, OHF: dimension C 1850mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm.
BC: dimension A 1310mm, OHF: dimension C 1840mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
