BC: dimension A 1310mm, OHF: dimension C 1790mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm.
BC: dimension A 1570mm, OHF: dimension C 2080mm, wheel connection 112x5, wheel brake type 2361 with AAA, offset (ET) 30mm, swing arm position 15°, axle profile 97mm.
BC: dimension A 1550mm, OHF: dimension C 2080mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm.
BC: dimension A 1570mm, OHF: dimension C 2080mm, wheel connection 112x5, wheel brake type 2361, offset (ET) 30mm, swing arm position 15°, axle profile 97mm.
BC: dimension A 1400mm, OHF: dimension C 1870mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
BC: dimension A 1580mm, OHF: dimension C 2090mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm.
BC: dimension A 1500mm, OHF: dimension C 1980mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 30mm, swing arm position 30°, axle profile 97mm, ball-head wheel bolts M12x1.5.
BC: dimension A 1550mm, OHF: dimension C 2038mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
BC: dimension A 1730mm, OHF: dimension C 2260mm, wheel connection 112x5, wheel brake type 2361, offset (ET) 30mm, swing arm position 0°, axle profile 97mm, no wheel bolts.
