total length K (at -5°) 4152mm, drawbar length E 2850mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at -5°) 3592mm, drawbar length E 2290mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at -5°) 3512mm, drawbar length E 2210mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at -5°) 3432mm, drawbar length E 2130mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at -5°) 3352mm, drawbar length E 2050mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at -5°) 3192mm, drawbar length E 1890mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 3512mm, drawbar length E 2210mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 2632mm, drawbar length E 1330mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 3192mm, drawbar length E 1890mm, drawbar section 80x140x4mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 2552mm, drawbar length E 1250mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at 0°) 2552mm, drawbar length E 1250mm, drawbar section 80x140x4mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at 0°) 3756mm, drawbar length E 2450mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at 0°) 3916mm, drawbar length E 2610mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at 0°) 2796mm, drawbar length E 1490mm, drawbar section 80x140x4mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at 0°) 3836mm, drawbar length E 2530mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 3676mm, drawbar length E 2370mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 3516mm, drawbar length E 2210mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 3196mm, drawbar length E 1890mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 2796mm, drawbar length E 1490mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 3356mm, drawbar length E 2050mm, drawbar section 80x140x4mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at -5°) 3832mm, drawbar length E 2530mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 3112mm, drawbar length E 1810mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 2952mm, drawbar length E 1650mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 3672mm, drawbar length E 2370mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
