total length K (at -5°) 3992mm, drawbar length E 2690mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 2872mm, drawbar length E 1570mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 3352mm, drawbar length E 2050mm, drawbar section 80x140x4mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at 0°) 3996mm, drawbar length E 2690mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at 0°) 2556mm, drawbar length E 1250mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 3832mm, drawbar length E 2530mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 3032mm, drawbar length E 1730mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 2453mm, drawbar length E 1250mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 4072mm, drawbar length E 2770mm, drawbar section 80x140x4mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 3512mm, drawbar length E 2210mm, drawbar section 80x140x4mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 4072mm, drawbar length E 2770mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at -5°) 2792mm, drawbar length E 1490mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 3352mm, drawbar length E 2050mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 3916mm, drawbar length E 2610mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at 0°) 2716mm, drawbar length E 1410mm, drawbar section 80x140x4mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at 0°) 3356mm, drawbar length E 2050mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 2956mm, drawbar length E 1650mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at -5°) 3352mm, drawbar length E 2050mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at 0°) 2552mm, drawbar length E 1250mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 3272mm, drawbar length E 1970mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 3992mm, drawbar length E 2690mm, drawbar section 80x140x4mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 3912mm, drawbar length E 2610mm, drawbar section 80x140x4mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 3912mm, drawbar length E 2610mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at -5°) 3832mm, drawbar length E 2530mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
