Home / CHASSIS PARTS / CHASSIS PARTS SCHLEGL / OVERRUN DEVICES / HEIGHT-ADJUSTABLE OVERRUN DEVICES / HEIGHT-ADJUSTABLE OVERRUN DEVICES TYPE SFH20 WITH DRAWBAR SECTION 1400 TO 2000KG / Steday leg □90mm square, side crank and reductions gears, double speed, three-stage, type DG 487/3SFW, for agricultural machines and trailers, machines for building industry, implements for road maintenance and snow
screw stroke (extended length) 360mm, maxi. static load 5440kg, dimension B 600mm, dimension C 440mm, dimension D 770mm, dimension E 225mm, dimension G 280mm, dimension H 400mm. Read more...
| Outer tube |
□90mm square |
| Screw stroke (extended length) | 360mm |
| Maxi. static load | 5440kg |
| Dimension B |
600mm |
| Dimension C |
440mm |
| Dimension D |
770mm |
| Dimension E |
225mm |
| Dimension G | 280mm |
| Dimension H | 400mm |
Here, you can find the catalogue page(s) as a convenient PDF download.
