connection 167mm, nose load 100kg, drawbar installation version top + bottom, combined with AL-KO wheel brake 1637 / 2051, without hitch components. Read more...

Wishlist: Add to comparison:
Order no. 1732320
Type EH09
Total weight in kg 450-900
Imposed load in kg 100
Drawbar installation version
top / bottom
Change-over relay lever? no
Can be combined with wheel brake
1637 / 2051
For jockey wheel
48mm
Hitch mounted no
ECE test report no. Overrun device: R13: CD97/001
ECE type approval no. Drawbar installation: E1 55R-01 10349



Here, you can find the catalogue page as a convenient PDF download.
You can also enter the part no. from the catalogue as a search term in our online store.

... ...
