Home / CHASSIS PARTS / CHASSIS PARTS AL-KO / OVERRUN DEVICES / HEIGHT-ADJUSTABLE OVERRUN DEVICES / OVERRUN DEVICES HEIGHT-ADJUSTABLE PRODUCT LINE 101 VB COMPACT / Overrun device square type ZAAQ 1.6-3, 800 to 1600kg, 4024948
connection dimension B 70mm, nose load 100kg, combined with BPW wheel brake S1704-7, S2005-7 and S2504-7 RASK, with coupling head AK 301. Read more...
| Permitted gross weight (kg) | 800-1600 |
| Sales designation (type) | ZAAQ 1.6-3 |
| Order No. | 4024948 |
| Reference No. |
| Push-on fit on square tube dimension B |
70mm |
| Perm. nose load (kg) |
100 |
| Combined wheel brakes (RASK) | S1704-7 and S2005-7 |
| ECE test code | E1 55R-011997 |
| Replacement part identification number (ETI) NEW | 827005 |
| Replacement part identification number (ETI) OLD |
