total length K (at -5°) 3032mm, drawbar length E 1730mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 2361. Read more...

Wishlist: Add to comparison:

Part no. 20059130
Overrun device cpl. with drawbar section mounted (without hitch components)

Total length K at -5° 3032mm
Drawbar length E 1730mm
Intermediate piece 700mm
For wheel brake 2361

* = DIN drawbar eye (the dimensions must be recalculated for other hitch components)

Original operating instructions
Replacement part identification number 811641

TECHNOLOGY
Type overrun device 161 VB-2 OPTIMA
Intermediate piece with drawbar section 162 VB-2-OPTIMA
Permissible nose load with DIN eye 100kg
Permissible nose load with coupling head 100kg

ECE test report no.:
Overrun device: 361-117-12
ECE type approval no.:
Drawbar installation: E1 55R-01 1157

Changeover relay lever: No

Here, you can find the catalogue page as a convenient PDF download.
You can also enter the part no. from the catalogue as a search term in our online store.

... ...
