screw stroke (extended length) 470mm, maxi. static load 10000kg, dimension B 790mm, dimension C 470mm, dimension D 940mm, dimension E 250mm, dimension G 245mm, dimension H 335mm, dimension I 210mm. Read more...

Wishlist: Add to comparison:
Outer tube
□110mm square
Screw stroke (extended length) 470mm
Maxi. static load 12000kg
Dimension B
790mm
Dimension C 470mm
Dimension D
940mm
Dimension E
250mm
Dimension G
245mm
Dimension H 335mm
Dimension I 210mm



Here, you can find the catalogue page(s) as a convenient PDF download.

... ...
