total length A 3290mm, drawbar length C 2030mm, drawbar section 100x100x6mm, perm. nose load 100kg, with coupling head AK 270, for wheel brake 1637 / 2051.
wheel load per hub up to max. 140 km/h 375kg, up to max. 40 km/h 450kg, wheel connection (G) 100x4, thread M12x1.5, offset 27-45, dimension A 203.5mm, dimension B 83.5mm, dimension C 39.5mm, bearing type Compact.
wheel load per hub up to max. 140 km/h 650kg, up to max. 40 km/h 750kg, wheel connection (G) 100x4, thread M12x1.5, offset 27-33, dimension A 300mm, dimension B 58mm, dimension C 41mm, dimension D 160mm, bearing type 34/64/37.
sheath length (H) 350mm, cable length (S) 560mm, can be used with wheel brake 3062 and 3081 from year of manufacture 01/1989, bell internal diam. 25.5mm, outside 30mm.
sheath length (H) 1430mm, cable length (S) 1640mm, can be used with wheel brake 1636G, 1637, 2051 and 2361 from year of manufacture 01/1989, bell internal diam. 23.3mm, outside 26mm.
sheath length (H) 890mm, cable length (S) 1100mm, can be used with wheel brake 1636G, 1637, 2051 and 2361 from year of manufacture 01/1989, bell internal diam. 23.3mm, outside 26mm.
