total length K (at -5°) 3116mm, drawbar length E 1810mm, drawbar section 100x160x5mm, intermediate piece 600mm, perm. nose load 120kg, without hitch components, for wheel brake 2361.
total length K (at -5°) 3676mm, drawbar length E 2370mm, drawbar section 100x160x5mm, intermediate piece 700mm, perm. nose load 120kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at -5°) 2792mm, drawbar length E 1490mm, drawbar section 80x140x4mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at 0°) 3676mm, drawbar length E 2370mm, drawbar section 80x140x4mm, intermediate piece 600mm, perm. nose load 100kg, without hitch components, for wheel brake 2361.
total length K (at 0°) 2876mm, drawbar length E 1570mm, drawbar section 80x140x4mm, intermediate piece 700mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 3116mm, drawbar length E 1810mm, drawbar section 80x140x4mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
connection 166mm, nose load 100kg, drawbar installation version bottom, can be combined with AL-KO wheel brake 2361 with coupling head AK 161, Soft-Dock.
connection 166mm, nose load 100kg, drawbar installation version top, can be combined with AL-KO wheel brake 1637 / 2051, with coupling head AK 161, Soft-Dock.
connection 130mm, nose load 75kg, drawbar installation version top, can be combined with AL-KO wheel brake 1636G / 1637, with coupling head AK 161, Soft-Dock.
rim size 4x13, hole number 4, rim centre hole Ø 57mm, bolt circle 100mm, offset +30, radial, tyre 165/70 R 13, load index 84N, load capacity 500kg at 140km/h.
rim size 4x13, hole number 5, rim centre hole Ø 67mm, bolt circle 112mm, offset +30, radial, tyre 165/70 R 13, load index 84N, load capacity 500kg at 140km/h.
