for axle CB 1805, permitted gross weight of the trailer 3500kg, axle profile dimension K 95mm square, for drawbar section square 120x120mm, 150x132mm and 150x150mm.
drawbar length L 1900mm, measure B 0-693mm, FD at max. 2000kg: 3000mm, drawbar section K square 120mm, spacer V 800mm, perm. nose load 150kg, without hitch components, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
drawbar length L 2500mm, FD at max. 3500kg: 3050mm, drawbar section K square 120x10mm, spacer V 550mm, perm. nose load 150kg, with drawbar eye DIN 40.0-02, for wheel brake S 2005-7, S 2504-7 and S 3006-7.
drawbar length L 1900mm, FD at max. 3500kg: 3050mm, drawbar section K square 120x10mm, spacer V 550mm, perm. nose load 150kg, with drawbar eye DIN 40.0-02, for wheel brake S 2005-7, S 2504-7 and S 3006-7.
drawbar length L 2800mm, FD at max. 2700kg: 2820mm, drawbar section K square 120x6.3mm, spacer V 500mm, perm. nose load 150kg, with coupling head EM 350 R-D-K1212, for wheel brake S 2005-7 and S 2504-7.
drawbar length L 3500mm, FD at max. 1600kg: 1200mm, drawbar section K square 70x5.0mm, measure HA 50mm, thread G M10, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
drawbar length L 3500mm, FD at max. 1350kg: 1210mm, drawbar section K square 70x4.0mm, measure HA 50mm, thread G M10, perm. nose load 100kg, with coupling head EM 150 R-B, for wheel brake S 1704-7 and S 2005-7.
connection 166mm, nose load 100kg, drawbar installation version top, combined with BPW wheel brake S1704-7 and S2005-7 RASK, with coupling head EM 150 R-A.
drawbar length L 1590mm, drawbar section K 108/90mm, with DIN drawbar eye dimension A 635mm, height B 0-375mm, intermediate piece V 500mm, perm. nose load 150kg.
