rim size 7x12, hole number 5, rim centre hole Ø 67mm, bolt circle 112mm, offset -4, radial, tyre 225/55 R 12 C, load index 112N, 10 PR, load capacity 950kg at 140km/h.
rim size 4.50x13, hole number 4, rim centre hole Ø 58.6mm, bolt circle 98mm, offset +30, colour silver RAL9006, C60 taper-head, load capacity 580kg at 140km/h.
build design radial, tyre size 185/60 R 12 C, TL (tubeless), load index 104, speed index N, tread KR16, specification M+S, load capacity 900kg at 140km/h, inflation pressure 6.5 bar.
build design radial, tyre size 195/50 R 13, TL (tubeless), load index 104/101, speed index N, tread FT 02, specification M+S, load capacity 900kg at 140km/h, inflation pressure 6.5 bar.
BC: dimension A 1650mm, OHF: dimension C 2200mm, wheel connection 205x6, wheel brake type 3081 A, offset (ET) 0mm, swing arm position 20°, axle profile 120mm, wheel nuts M18x1.5 ball.
BC: dimension A 1000mm, OHF: dimension C 1530mm, wheel connection 205x6, wheel brake type 3081 A, offset (ET) 0mm, swing arm position 35°, axle profile 120mm, wheel nuts M18x1.5 ball.
BC: dimension A 1000mm, OHF: dimension C 1530mm, wheel connection 205x6, wheel brake type 3081 A, offset (ET) 0mm, swing arm position 20°, axle profile 120mm, wheel nuts M18x1.5 ball.
BC: dimension A 1750mm, OHF: dimension C 2280mm, wheel connection 205x6, wheel brake type 3081 A, offset (ET) 0mm, swing arm position 20°, axle profile 120mm, wheel nuts M18x1.5 ball.
BC: dimension A 1670mm, OHF: dimension C 2200mm, wheel connection 205x6, wheel brake type 3081 A, offset (ET) 0mm, swing arm position 20°, axle profile 120mm, wheel nuts M18x1.5 ball.
BC: dimension A 1580mm, OHF: dimension C 2110mm, wheel connection 205x6, wheel brake type 3081 A, offset (ET) 0mm, swing arm position 20°, axle profile 120mm, wheel nuts M18x1.5 ball.
BC: dimension A 1550mm, OHF: dimension C 2080mm, wheel connection 205x6, wheel brake type 3081 A, offset (ET) 0mm, swing arm position 20°, axle profile 120mm, wheel nuts M18x1.5 ball.
