drawbar length L 2500mm, measure B 0-693mm, FD at max. 2000kg: 3000mm, drawbar section K square 120mm, spacer V 800mm, perm. nose load 150kg, without hitch components, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
drawbar length L 1900mm, measure B 0-693mm, FD at max. 2000kg: 3000mm, drawbar section K square 120mm, spacer V 800mm, perm. nose load 150kg, without hitch components, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
drawbar length L 2500mm, measure B 0-693mm, FD at max. 1600kg: 3000mm, drawbar section K square 120mm, spacer V 800mm, perm. nose load 150kg, without hitch components, for wheel brake S 1704-7 and S 2005-7.
drawbar length L 1500mm, FD at max. 1300kg: 2223mm, drawbar section K round 88.9x8.8mm, spacer V 415mm, perm. nose load 100kg, with drawbar eye DIN 40.0-01, for wheel brake S 1704-7 and S 2005-7.
drawbar length L 3000mm, FD at max. 2000kg: 1360mm, drawbar section K square 80x5.0mm, measure HA 55mm, thread G M10, perm. nose load 150kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
drawbar length L 2300mm, FD at max. 1350kg: 1210mm, drawbar section K square 70x5.0mm, measure HA 50mm, thread G M10, perm. nose load 100kg, with coupling head EM 150 R-B, for wheel brake S 1704-7 and S 2005-7.
drawbar length L 2300mm, FD at max. 2000kg: 1360mm, drawbar section K square 80x5.0mm, measure HA 55mm, thread G M10, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
connection 166mm, nose load 150kg, drawbar installation version top, combined with BPW wheel brake S2005-7, S2504-7 and S3006-7 RASK, with coupling head EM 350 R-D.
connection 166mm, nose load 150kg, drawbar installation version top + bottom, combined with BPW wheel brake S2005-7, S2504-7 and S3006-7 RASK, with coupling head EM 300 R-B.
drawbar length L 1090mm, drawbar section K 108/90mm, with DIN drawbar eye dimension A 534mm, height B 0-263mm, intermediate piece V 350mm, perm. nose load 150kg.
total length L 2200mm, drawbar section K dimension K 70x4mm, perm. nose load 75kg, coupling head EM 80 R-GK, including skid bracket, clamping bracket and plug holder.
rim size 6.75x17.5, hole number 6, rim centre hole Ø 161mm, bolt circle 205mm, offset 0, A2, radial, LKW tyre 245/70R17.5, load index 143/141J, 18 PR, load capacity 2750kg at 100km/h.
total length K (at 0°) 3570mm, drawbar length E 2270mm, drawbar section 120x160x6mm, intermediate piece 400mm, perm. nose load 150kg, without hitch components, for wheel brake 2051.
hole pattern 90x50mm, 4 holes Ø17mm, tensile load max. 3500kg, nose load 120kg, type approval no. E2 55R-0112212, D/Dc value 17.2 kN, for drawbar eyes 43x68mm or 42x76mm, Achs Ø32mm, dimension A 175mm, dimension B 222mm, dimension C 105mm.
