drawbar length L 1900mm, FD at max. 2700kg: 2453mm, drawbar section K square 120x6.3mm, spacer V 680mm, perm. nose load 150kg, with drawbar eye DIN 40.0-02, for wheel brake S 2005-7 and S 2504-7.
drawbar length L 2500mm, FD at max. 2700kg: 2820mm, drawbar section K square 120x6.3mm, spacer V 500mm, perm. nose load 150kg, with drawbar eye DIN 40.0-02, for wheel brake S 2005-7 and S 2504-7.
drawbar length L 2800mm, FD at max. 2000kg: 1526mm, drawbar section K round 101.6x10mm, spacer V 415mm, perm. nose load 100kg, with drawbar eye DIN 40.0-01, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
drawbar length L 2100mm, FD at max. 1300kg: 1664mm, drawbar section K round 88.9x8.8mm, spacer V 415mm, perm. nose load 100kg, with drawbar eye DIN 40.0-01, for wheel brake S 1704-7 and S 2005-7.
drawbar length L 2800mm, FD at max. 2700kg: 2453mm, drawbar section K square 120x6.3mm, spacer V 680mm, perm. nose load 150kg, with coupling head EM 350 R-D-K1212, for wheel brake S 2005-7 and S 2504-7.
drawbar length L 2500mm, FD at max. 2700kg: 2453mm, drawbar section K square 120x6.3mm, spacer V 680mm, perm. nose load 150kg, with coupling head EM 350 R-D-K1212, for wheel brake S 2005-7 and S 2504-7.
drawbar length L 1900mm, FD at max. 2700kg: 2820mm, drawbar section K square 120x6.3mm, spacer V 500mm, perm. nose load 150kg, with coupling head EM 350 R-D-K1212, for wheel brake S 2005-7 and S 2504-7.
drawbar length L 3500mm, FD at max. 2000kg: 1385mm, drawbar section K round 88.9x6.3mm, measure HA 58mm, thread G M10, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
drawbar length L 1700mm, length A 1100mm, drawbar section K 88.9x5.6mm, thread G M10, perm. nose load 100kg, with coupling head EM 150 R-B, for wheel brake S 1704-7 and S 2005-7.
drawbar length L 1500mm, length A 1100mm, drawbar section K 88.9x5.6mm, thread G M10, perm. nose load 100kg, with coupling head EM 150 R-B, for wheel brake S 1704-7 and S 2005-7.
connection 166mm, nose load 100kg, drawbar installation version top + bottom, combined with BPW wheel brake S1704-7, S2005-7 and S2504-7 RASK, with coupling head EM 220 R-A.
drawbar length L 1590mm, drawbar section K 108/90mm, with DIN drawbar eye dimension A 568mm, height B 0-300mm, intermediate piece V 400mm, perm. nose load 150kg.
drawbar length L 1590mm, drawbar section K 108/90mm, with DIN drawbar eye dimension A 534mm, height B 0-263mm, intermediate piece V 350mm, perm. nose load 150kg.
drawbar length L 1075mm, drawbar section K 70mm, with DIN drawbar eye dimension A 655mm, height B 0-375mm, intermediate piece V 500mm, perm. nose load 75kg.
