BPW Braked axle 750kg SWING, axle type CB 855 for braked trailers

BPW Braked axle 750kg SWING, axle type CB 855

DETAILS

  • Speed up to 140 km/h
  • Drawbar connection: Clamping shells see Accessories
  • Axle shock absorber see Accessories
  • Wheel connections: 98x4; 130x4 on demand
  • Special axle mounts and drawbar connections on demand
  • Also available with watertight bearings
  • Axle body fully hop-dip galvanised: Permanent surface protection
  • Independent wheel suspension: Optimum compensation of uneven road surfaces
  • Maintenance-free suspension: Lower maintenance costs
  • Sturdy axle construction: Suitable for extreme loads such as off-road or construction sites
  • Sturdy, maintenance-free spreadlever brakes with auto-reverse: Simple adjustment of the brake from outside the wheel, subsequent connection of the brake cables possible without removal of the brake drum
  • Compact bearings (standard in the automotive industry): Maintenance-free, long service life, protected against dirt and water, lubricated for life with special grease
  • Incl. shock absorber bracket

How do I find the right axle?

Here, you can find the catalogue page as a convenient PDF download.
You can also enter the part no. from the catalogue as a search term in our online store.

Braked axle 850kg SWING axle type CB 855, 46.16.382.030
BC: dimension AM 1000mm, OHF: dimension FL 1430mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 482,10 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.031
BC: dimension AM 1050mm, OHF: dimension FL 1480mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 416,90 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.032
BC: dimension AM 1100mm, OHF: dimension FL 1530mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 487,10 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.033
BC: dimension AM 1150mm, OHF: dimension FL 1580mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 423,90 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.034
BC: dimension AM 1200mm, OHF: dimension FL 1630mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 492,00 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.035
BC: dimension AM 1250mm, OHF: dimension FL 1680mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 495,70 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.036
BC: dimension AM 1300mm, OHF: dimension FL 1730mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 501,90 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.037
BC: dimension AM 1350mm, OHF: dimension FL 1780mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 438,90 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.038
BC: dimension AM 1400mm, OHF: dimension FL 1830mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 501,90 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.039
BC: dimension AM 1450mm, OHF: dimension FL 1880mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 445,90 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.040
BC: dimension AM 1500mm, OHF: dimension FL 1930mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 506,80 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.041
BC: dimension AM 1550mm, OHF: dimension FL 1980mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 453,90 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.042
BC: dimension AM 1600mm, OHF: dimension FL 2030mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 511,70 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.043
BC: dimension AM 1650mm, OHF: dimension FL 2080mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 461,90 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.044
BC: dimension AM 1700mm, OHF: dimension FL 2130mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 516,60 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.045
BC: dimension AM 1750mm, OHF: dimension FL 2180mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 469,90 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.046
BC: dimension AM 1800mm, OHF: dimension FL 2230mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 521,60 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.047
BC: dimension AM 1850mm, OHF: dimension FL 2280mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 474,90 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 855, 46.16.382.048
BC: dimension AM 1900mm, OHF: dimension FL 2330mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 526,50 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 850kg SWING axle type CB 855, 46.16.382.070
BC: dimension AM 1000mm, OHF: dimension FL 1430mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 482,10 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 850kg SWING axle type CB 855, 46.16.382.071
BC: dimension AM 1050mm, OHF: dimension FL 1480mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 416,90 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 850kg SWING axle type CB 855, 46.16.382.072
BC: dimension AM 1100mm, OHF: dimension FL 1530mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 487,10 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 850kg SWING axle type CB 855, 46.16.382.073
BC: dimension AM 1150mm, OHF: dimension FL 1580mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 423,90 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 850kg SWING axle type CB 855, 46.16.382.074
BC: dimension AM 1200mm, OHF: dimension FL 1630mm, wheel connection 112x5, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, ball-head wheel bolts M12x1.5.
Price 492,00 EUR Incl. tax Excl. Shipping costs
