RUNNING WELL FOR YOU. BPW BERGISCHE AXLES

AL-KO Technology Paderborn GmbH specialises in the development and manufacture of complete running gear technology for car trailers and self-propelled vehicles. The location has developed from a labour-intensive wagon maker into an innovative, modern industrial company. Since 2017 the former BPW Fahrzeugtechnik has been part of the global technology company DexKo Global Inc., a worldwide market leader for trailer axles and chassis components in the lightweight segment. Read more...

Underpinning Your Progress.
The range of running gear for towable machinery, car and light truck trailers, caravans and cab & engine vehicles.



Overrun device square type ZAAQ 2.5-3, 1350 to 2500kg, 48.41.981.000
BPW (AL-KO) Overrun device square type ZAAQ 2.5-3, 1350 to 2500kg, 48.41.981.000
connection dimension B 100mm, nose load 100kg, combined with BPW wheel brake S2005-7 and S2504-7 RASK, with coupling head EM 300 R-B.
Price 1.560,70 EUR Incl. tax Excl. Shipping costs
Drawbar eye Italy 45.0-02
BPW (AL-KO) Drawbar eye Italy 45.0-02
dimension K 51.8mm, dimension S 45mm, dimension L 115mm, EG e1 1149 94/20, nose load 150kg, perm. gross weight 3500kg, suitable for types ZAA 3.5-1, ZKV 25/35 and ZAV 3.5-1.
Price 386,90 EUR Incl. tax Excl. Shipping costs
Drawbar eye DIN 40.0-01
BPW (AL-KO) Drawbar eye DIN 40.0-01
dimension K 40.8mm, dimension S 40mm, dimension L 200mm, EG e1 0347 94/20, nose load 100kg, perm. gross weight 2000kg, suitable for types ZAA 1.3-1, 2.0-1, ZKV 13/20 and ZRV 13/20.
Price 233,80 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 2.0-3, 1250 to 2000kg, 48.36.581.202
BPW (AL-KO) Overrun device V type ZAF 2.0-3, 1250 to 2000kg, 48.36.581.202
connection 166mm, nose load 150kg, drawbar installation version top + bottom, combined with BPW wheel brake S1704-7, S2005-7 and S2504-7 RASK, with coupling head EM 220 R-A.
Price 365,00 EUR Incl. tax Excl. Shipping costs
Towbar connection (pair) ZEA 2.8-1.1 B to 2800kg, 05.447.26.18.1
BPW (AL-KO) Towbar connection (pair) ZEA 2.8-1.1 B to 2800kg, 05.447.26.18.1
total length GL 2150mm, nose load 150kg.
Price 346,30 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 5.0-1.1 height-adjustable with drawbar section up to 5000kg, 47.62.403.001
BPW (AL-KO) Towbar connection ZOV 5.0-1.1 height-adjustable with drawbar section up to 5000kg, 47.62.403.001
drawbar length L 2300mm, drawbar section K 127mm, with DIN drawbar eye dimension A 716mm, height B 0-413mm, intermediate piece V 550mm, perm. nose load 400kg.
Price 1.917,40 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.005
BPW (AL-KO) Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.005
drawbar length L 1090mm, drawbar section K 108/90mm, with DIN drawbar eye dimension A 635mm, height B 0-375mm, intermediate piece V 500mm, perm. nose load 150kg.
Price 1.263,80 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.001
BPW (AL-KO) Towbar connection ZOV 2.5-1.1 height-adjustable with drawbar section up to 2500kg, 47.41.403.001
drawbar length L 1090mm, drawbar section K 108/90mm, with DIN drawbar eye dimension A 501mm, height B 0-225mm, intermediate piece V 300mm, perm. nose load 150kg.
Price 1.218,70 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 1.2-1.1 B height-adjustable with drawbar section up to 1200kg, 47.23.403.019
BPW (AL-KO) Towbar connection ZOV 1.2-1.1 B height-adjustable with drawbar section up to 1200kg, 47.23.403.019
drawbar length L 1570mm, drawbar section K 82.5mm, with DIN drawbar eye dimension A 655mm, height B 0-375mm, intermediate piece V 500mm, perm. nose load 100kg.
Price 1.004,60 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 1.2-1.1 B height-adjustable with drawbar section up to 1200kg, 47.23.403.010
BPW (AL-KO) Towbar connection ZOV 1.2-1.1 B height-adjustable with drawbar section up to 1200kg, 47.23.403.010
drawbar length L 1070mm, drawbar section K 82.5mm, with DIN drawbar eye dimension A 523mm, height B 0-225mm, intermediate piece V 300mm, perm. nose load 100kg.
Price 957,80 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 0.75-1 B height-adjustable with drawbar section up to 750kg, 47.14.401.002
BPW (AL-KO) Towbar connection ZOV 0.75-1 B height-adjustable with drawbar section up to 750kg, 47.14.401.002
drawbar length L 1075mm, drawbar section K 70mm, with coupling head dimension A 675mm, height B 0-375mm, intermediate piece V 500mm, perm. nose load 75kg.
Price 715,00 EUR Incl. tax Excl. Shipping costs
Spread hinge lock
BPW (AL-KO) Spread hinge lock
can be used with wheel brake S 3006-7 RASK and S 3006-7 SK.
Price 58,50 EUR Incl. tax Excl. Shipping costs
Spread hinge lock
BPW (AL-KO) Spread hinge lock
can be used with wheel brake S 2504-7 RASK and S 2504-7 SK.
Price 22,80 EUR Incl. tax Excl. Shipping costs
Original ball-head wheel bolt M12x1.5, set of 10 pieces
BPW (AL-KO) Original ball-head wheel bolt M12x1.5, set of 10 pieces
thread 25mm, wrench size AF 19, bolt quality 8.8, maximum permitted tightening torque 90 Nm.
Price 24,90 EUR Incl. tax Excl. Shipping costs
Axle without brakes 2100kg Peugeot Boxer axle type DB 2100, 37.92.000.007
BPW (AL-KO) Axle without brakes 2100kg Peugeot Boxer axle type DB 2100, 37.92.000.007
BC: dimension AM 1220mm, OHF: dimension FL 1654mm, connection 82x82mm, WITHOUT wheel brake, swing arm position 15°, axle profile 92mm.
Price 3.695,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1500kg axle type CB 1505, 46.27.379.293
BPW (AL-KO) Braked axle SWING 1500kg axle type CB 1505, 46.27.379.293
BC: dimension AM 1900mm, OHF: dimension FL 2375mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 750,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1800kg RONDO axle type DB 1805, 45.32.368.492
BPW (AL-KO) Braked axle 1800kg RONDO axle type DB 1805, 45.32.368.492
BC: dimension AM 1210mm, OHF: dimension FL 1760mm, wheel connection 112x5, wheel brake type S 2504-7 RASK, offset (ET) 35mm, swing arm position 13°, axle profile 92mm, ball-head wheel bolts M12x1.5.
Price 3.150,00 EUR Incl. tax Excl. Shipping costs
Shock absorber, Ausführung mit zwei Augen
BPW (AL-KO) Shock absorber, Ausführung mit zwei Augen
suitable for overrun devices ZAV 2.7-1 and ZAV 2.7-4, label old 02.3722.50.00, new 4014922.
Price 219,90 EUR Incl. tax Excl. Shipping costs
Shock absorber, version with two eyes
BPW (AL-KO) Shock absorber, version with two eyes
suitable for overrun devices ZAAQ 1.6-3, ZAF 1.35-3, ZAF 1.5-2 and ZAF 1.6-3, label old 02.3722.75.00, new 4014932.
Price 69,90 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1350kg axle type CB 1355, 46.25.379.172
BPW (AL-KO) Braked axle SWING 1350kg axle type CB 1355, 46.25.379.172
BC: dimension AM 900mm, OHF: dimension FL 1340mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 25°, axle profile 80mm.
Price 765,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1500kg axle type CB 1505, 46.27.379.787
BPW (AL-KO) Braked axle SWING 1500kg axle type CB 1505, 46.27.379.787
BC: dimension AM 1550mm, OHF: dimension FL 2050mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 25°, axle profile 95mm.
Price 1.595,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1500kg axle type SCB 1505, 46.27.379.925
BPW (AL-KO) Braked axle 1500kg axle type SCB 1505, 46.27.379.925
BC: dimension AM 1513mm, OHF: dimension FL 2035mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30-35mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 1.399,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1500kg axle type CB 1505, 46.27.380.008
BPW (AL-KO) Braked axle SWING 1500kg axle type CB 1505, 46.27.380.008
BC: dimension AM 1500mm, OHF: dimension FL 1950mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 699,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1350kg axle type CB 1355, 46.24.316.648
BPW (AL-KO) Braked axle 1350kg axle type CB 1355, 46.24.316.648
BC: dimension AM 1082mm, OHF: dimension FL 1550mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30-35mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 1.050,00 EUR Incl. tax Excl. Shipping costs
Page 68 of 90
