AL-KO

Home / Brands / AL-KO

JUST ORIGINAL PARTS

LIFE-TIME SUPPORT

SALE

POSITIVE REVIEWS

Wheel brake 1637 AR (pair)
AL-KO Wheel brake 1637 AR (pair)
wheel load per hub 900kg, wheel connection (G) 112x5, thread M12x1.5, offset (ET) 27-33mm, axle stub 51mm.
Price 467,00 EUR Incl. tax Excl. Shipping costs
Axle with pneumatic brakes 3000kg axle type BL 3000 with shock absorber bracket
AL-KO Axle with pneumatic brakes 3000kg axle type BL 3000 with shock absorber bracket
BC: dimension A 1330mm, OHF: dimension C 1800mm, wheel connection 205x6, wheel brake type 3062 AR, offset (ET) 0mm, swing arm position 25°, wheel nut ball M18x1.5.
Price 3.678,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1600kg for hydraulic brake force transmission with top hat profile
AL-KO Braked axle 1600kg for hydraulic brake force transmission with top hat profile
BC: dimension A 1470mm, OHF: dimension C 1900mm, wheel connection 112x5, wheel brake type 2361, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.006,70 EUR Incl. tax Excl. Shipping costs
Brake away cable with ring
AL-KO Brake away cable with ring
length 1650mm, can be used with FTF FA0.9, FA1.4, FA1.5, FA2.5 and FA3.5.
Price 41,90 EUR Incl. tax Excl. Shipping costs
Bowden cable 562567 for overrun device with thread and eyelet
AL-KO Bowden cable 562567 for overrun device with thread and eyelet
sheath length (A) 870mm, cable length (B) 1110mm, cable thickness (C) 5mm, thread (D) M10, suitable for types FA 0.9 and FA 1.4.
Price 126,00 EUR Incl. tax Excl. Shipping costs
Bowden cable 217743 for overrun device with thread and eyelet
AL-KO Bowden cable 217743 for overrun device with thread and eyelet
sheath length (A) 550mm, cable length (B) 760mm, cable thickness (C) 5mm, thread (D) M10, suitable for types 1.3 VB with automatic reverse.
Price 68,90 EUR Incl. tax Excl. Shipping costs
Lowering axles down to 210mm, axle type BRA 1800-9, tandem 3500kg
AL-KO Lowering axles down to 210mm, axle type BRA 1800-9, tandem 3500kg
BC: dimension A 1900mm, OHF: dimension C 2450mm, wheel connection 112x5, wheel brake type 2361, offset (ET) 27-35mm, ball-head wheel bolts M12x1.5, hydraulic cylinder, cylinder spacing: dimension S 1640mm.
Price 5.800,00 EUR Incl. tax Excl. Shipping costs
Lowering axle down to 210mm, axle type BRA 1800-01, single axle 1300kg
AL-KO Lowering axle down to 210mm, axle type BRA 1800-01, single axle 1300kg
BC: dimension A 1800mm, OHF: dimension C 2350mm, wheel connection 112x5, wheel brake type 2051 Ab, offset (ET) 27-35mm, ball-head wheel bolts M12x1.5, hydraulic cylinder, cylinder spacing: dimension S 1540mm.
Price 2.802,00 EUR Incl. tax Excl. Shipping costs
Slave cylinder attachment kit for tandem axle A-frame chassis
AL-KO Slave cylinder attachment kit for tandem axle A-frame chassis
screw-on bracket, slave cylinder + small parts (see technical drawing), for axle beam Ø: 110mm (= max. gross weight tandem 3500kg)
Price 1.033,00 EUR Incl. tax Excl. Shipping costs
Brake back plate left 2361
AL-KO Brake back plate left 2361
for wheel brake AL-KO 2361, brake size 230x60mm, surface treatment galvanised.
Price 212,00 EUR Incl. tax Excl. Shipping costs
Brake back plate right 2361
AL-KO Brake back plate right 2361
for wheel brake AL-KO 2361, brake size 230x60mm, surface treatment galvanised.
Price 102,00 EUR Incl. tax Excl. Shipping costs
Brake back plate left 2051
AL-KO Brake back plate left 2051
for wheel brake AL-KO 2051, brake size 200x50mm, surface treatment galvanised.
Price 89,90 EUR Incl. tax Excl. Shipping costs
Square overrun device type 251 S - ZE 252R with removable drawbar section from 1500 to 2600kg
AL-KO Square overrun device type 251 S - ZE 252R with removable drawbar section from 1500 to 2600kg
total length A 2645mm, drawbar length C 1385mm, drawbar section 88.9x5.6mm, perm. nose load 100kg, with drawbar eye D40/F, for wheel brake 2361.
Price 1.611,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 251 S - ZE 252R with removable drawbar section from 1500 to 2600kg
AL-KO Square overrun device type 251 S - ZE 252R with removable drawbar section from 1500 to 2600kg
total length A 2485mm, drawbar length C 1225mm, drawbar section 88.9x5.6mm, perm. nose load 100kg, with drawbar eye D40/F, for wheel brake 2361.
Price 1.577,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 251 S - ZE 252R with removable drawbar section from 1500 to 2600kg
AL-KO Square overrun device type 251 S - ZE 252R with removable drawbar section from 1500 to 2600kg
total length A 3445mm, drawbar length C 2185mm, drawbar section 88.9x5.6mm, perm. nose load 100kg, with coupling head AK 270, for wheel brake 2361.
Price 1.739,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
AL-KO Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
total length A 3370mm, drawbar length C 1817mm, drawbar section 120x120x8mm, perm. nose load 150kg, without hitch component, for wheel brake 3062 / 3081.
Price 3.644,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
AL-KO Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
total length A 3450mm, drawbar length C 1897mm, drawbar section 120x120x8mm, perm. nose load 150kg, without hitch component, for wheel brake 2361.
Price 3.665,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
AL-KO Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
total length A 4010mm, drawbar length C 2457mm, drawbar section 120x120x8mm, perm. nose load 150kg, without hitch component, for wheel brake 2051.
Price 3.759,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
AL-KO Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
total length A 3770mm, drawbar length C 2217mm, drawbar section 120x120x8mm, perm. nose load 150kg, without hitch component, for wheel brake 2051.
Price 3.697,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
AL-KO Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
total length A 2810mm, drawbar length C 1337mm, drawbar section 120x120x8mm, perm. nose load 150kg, without hitch component, for wheel brake 2051.
Price 3.539,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
AL-KO Square overrun device type 2,8 VB/1-C - K35-S with sideways swivelling drawbar section from 2500 to 3500kg
total length A 2730mm, drawbar length C 1177mm, drawbar section 120x120x8mm, perm. nose load 150kg, without hitch component, for wheel brake 2051.
Price 3.519,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 251 S - K26-S with sideways swivelling drawbar section from 1500 to 2600kg
AL-KO Square overrun device type 251 S - K26-S with sideways swivelling drawbar section from 1500 to 2600kg
total length A 3450mm, drawbar length C 2190mm, drawbar section 100x100x6mm, perm. nose load 100kg, with coupling head AK 270, for wheel brake 1637 / 2051.
Price 1.961,00 EUR Incl. tax Excl. Shipping costs
Square overrun device type 161 S - K26-S with sideways swivelling drawbar section from 950 to 1600kg
AL-KO Square overrun device type 161 S - K26-S with sideways swivelling drawbar section from 950 to 1600kg
total length A 3610mm, drawbar length C 2350mm, drawbar section 100x100x6mm, perm. nose load 100kg, with coupling head AK 161, for wheel brake 1637 / 2051.
Price 1.845,00 EUR Incl. tax Excl. Shipping costs
Hub with stub for screwing in
AL-KO Hub with stub for screwing in
wheel load per hub up to max. 140 km/h 375kg, up to max. 40 km/h 450kg, wheel connection (G) 100x4, thread M12x1.5, offset 27-45, dimension A 203.5mm, dimension B 83.5mm, dimension C 39.5mm, bearing type Compact.
Price 68,90 EUR Incl. tax Excl. Shipping costs
Page 81 of 473
