total length K (at 0°) 2710mm, drawbar length E 1570mm, drawbar section 70x140x3mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length A 1735mm, drawbar length C 1025mm, drawbar section 100x100x5mm, perm. nose load 100kg, without hitch component, for wheel brake 2051 / 2361.
total length A 2790mm, drawbar length C 2080mm, drawbar section 100x100x5mm, perm. nose load 100kg, with coupling head AK 270, for wheel brake 1637 / 2051.
total length A 3270mm, drawbar length C 2560mm, drawbar section 100x100x4mm, perm. nose load 100kg, with coupling head AK 270, for wheel brake 1637 / 2051.
total length A 2649mm, drawbar length C 1939mm, drawbar section 100x100x4mm, perm. nose load 100kg, with coupling head AK 270, for wheel brake 1637/2051.
total length A 1690mm, drawbar length C 980mm, drawbar section 100x100x4mm, perm. nose load 100kg, with coupling head AK 270, for wheel brake 1637 / 2051.
total length A 1404mm, drawbar length C 737mm, drawbar section 70x70x4mm, perm. nose load 100kg, with coupling head AK 161, for wheel brake 1637 / 2051.
total length A 2165mm, drawbar length C 1540mm, drawbar section 70x70x4mm, perm. nose load 75kg, with coupling head AK 161, for wheel brake 1636G / 1637 / 2051.
total length K (at 0°) 3902mm, drawbar length E 2850mm, drawbar section 80x140x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 3822mm, drawbar length E 2770mm, drawbar section 80x140x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 3422mm, drawbar length E 2370mm, drawbar section 80x140x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 2782mm, drawbar length E 1730mm, drawbar section 80x140x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 2702mm, drawbar length E 1650mm, drawbar section 80x140x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 3139mm, drawbar length E 2130mm, drawbar section 70x140x3mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 3049mm, drawbar length E 2040mm, drawbar section 70x70x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 2569mm, drawbar length E 1560mm, drawbar section 70x70x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 2329mm, drawbar length E 1320mm, drawbar section 70x70x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 3369mm, drawbar length E 2360mm, drawbar section 70x70x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 2169mm, drawbar length E 1160mm, drawbar section 70x70x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 3379mm, drawbar length E 2370mm, drawbar section 70x110x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
