total length K (at 0°) 3110mm, drawbar length E 1970mm, drawbar section 70x140x3mm, intermediate piece 400mm, perm. nose load 100kg, without hitch components, for wheel brake 1637 / 2051.
total length K (at 0°) 2889mm, drawbar length E 1880mm, drawbar section 70x70x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 3299mm, drawbar length E 2290mm, drawbar section 70x110x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 3699mm, drawbar length E 2690mm, drawbar section 70x110x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 2419mm, drawbar length E 1410mm, drawbar section 70x110x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
total length K (at 0°) 1919mm, drawbar length E 910mm, drawbar section 70x110x4mm, intermediate piece 750mm, perm. nose load 100kg, without hitch components.
BC: dimension A 1355mm, OHF: dimension C 1865mm, wheel connection 100x4, wheel brake type 2051 A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
