total length K (at 0°) 2690mm, drawbar length E 1390mm, drawbar section 120x160x6mm, intermediate piece 400mm, perm. nose load 150kg, without hitch components, for wheel brake 2051.
packing unit 24 units, for towing hitch with 50mm ball, colour black similar to RAL 9011, the cardboard box is transport packaging and can be used as a sales display after being opened.
packing unit 20 units, suitable for coupling head type AK 301 and AK 351 PROFI, material rubber, colour red, the cardboard box is transport packaging and can be used as a sales display after being opened.
hole pattern 83x56mm, 4 holes Ø11mm, tensile load max. 3500kg, nose load 340kg, type approval no. E2 55R-0112209, D/Dc value 31 kN, for drawbar eyes 42x68mm or 42x76mm, dimension A 127mm, dimension B 140mm, dimension B' 185mm, dimension C 155mm.
weight range single axle 750kg, axle profile 71mm, swing arm standard degrees: 30°, drawbar section round 70mm and 88.9mm, rectangular width 70mm and 80mm, dimension A 175mm, dimension B 190mm, dimension C 80mm, dimension D 12.5mm, dimension E 12.5mm, dim
for axles AL-KO, suspension: hexagonal rubber suspension, axle profile 80mm, type Compact from year of manufacture 1995, type Plus from year of manufacture 1999, colour black.
for AL-KO axles trailing arm and semi-trailing arm, single axle up to 4000kg, tandem axle up to 7500kg, colour black, without articulation connection eyes and fixing bolts.
