wheel load per hub up to max. 140 km/h 650kg, up to max. 40 km/h 750kg, wheel connection (G) 112x5, thread M12x1.5, offset 27-33, dimension A 300mm, dimension B 58mm, dimension C 41mm, dimension D 160mm, bearing type 34/64/37.
wheel load per hub up to max. 140 km/h 650kg, up to max. 40 km/h 750kg, wheel connection (G) 100x4, thread M12x1.5, offset 27-33, dimension A 300mm, dimension B 58mm, dimension C 41mm, dimension D 160mm, bearing type 34/64/37.
wheel load per hub up to max. 140 km/h 425kg, up to max. 40 km/h 500kg, wheel connection (G) 112x5, thread M12x1.5, offset 27-45, dimension A 127mm, dimension B 51mm, dimension C 35mm, dimension D 162mm, dimension E 46mm, dimension F 65.5mm, bearing type
wheel load per hub up to max. 140 km/h 425kg, up to max. 40 km/h 500kg, wheel connection (G) 100x4, thread M12x1.5, offset 27-45, dimension A 127mm, dimension B 51mm, dimension C 35mm, dimension D 150mm, dimension E 46mm, dimension F 56.5mm, bearing type
wheel load per hub up to max. 140 km/h 375kg, up to max. 40 km/h 450kg, wheel connection (G) 112x5, thread M12x1.5, offset 27-33, dimension A 300mm, dimension B 53mm, dimension C 41mm, dimension D 145mm, bearing type 30/60/37.
wheel load per hub up to max. 140 km/h 250kg, up to max. 40 km/h 300kg, wheel connection (G) 100x4, thread M12x1.5, offset 0, dimension A 109mm, dimension B 38mm, dimension C 30mm, dimension D 145mm, dimension E 52mm, dimension F 56.5mm, bearing type 3020
for winch type 501 PLUS, 901 PLUS and 1201 PLUS, ETI 811697, 811697A, 811697C, 811697D, 811697E, 811702, 811702A, 811702B, 811717, 811717A, 811717B, 811717C and 811717D.
