Home / Braked half axles 1350kg axle type CBST 1354 - 46.25.379.478 / 479
BC: dimension A 270mm, OHF: dimension C 555mm, wheel connection 100x4, wheel brake type S 2005-7, offset (ET) 30-35mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5. Read more...
Part no. 46.25.379.478 / 479 (4002439)
| Braked half axles (pair) |
| Axle load per pair |
1350kg |
| Type | CBST 1354 |
| Wheel brake |
S 2005-7 RASK |
| Wheel connection |
100x4 |
| BC: dimension A | 270mm |
| OHF: dimension C | 555mm |
| Offset: ET |
30-35mm |
Original operating instructions
Replacement part identification number (ETI) OLD 811294
Replacement part identification number (ETI) NEW 811947
SCOPE OF DELIVERY
Half axles (pair)
Adapter bracket single axle loose
Single axle trailer compensation profile loose
Bowden cables loose
Wheel bolts loose
SURFACE TREATMENT
Hot-dip galvanised axle profile
